Niggliite

PtSn
IMA status
  • Approved
  • Grandfathered
IMA symbol
Nig
Discovered
1936
Also known as
  • Niggliiet

Where it forms, where it's found

Type locality
Waterfall gorge
  1. Insizwa
  2. Umzimvubu Local Municipality
  3. Alfred Nzo District Municipality
  4. Eastern Cape
  5. South Africa

-30.7835°, 29.3086°

30recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Silver-white
Tenacity
brittle
Density
13.4 g/cm³

Optical

Optical colour
pinkish to blue
Anisotropism
Very high, bright pinkish cream to very dark blue or black
Bireflectance
Strong, pinkish cream to pale cobalt-blue
Tropism
Anisotropic
Reflectance R%
(42.6,46.4) 400, (44.7,52.9) 440, (45.9,58.2) 480, (45.9,61.7) 520, (45.3,64.1) 560, (44.8,66.0) 600, (44.6,67.1) 640, (44.7,68.2) 680, (45.0,68.5) 700
Reflected-light panel
44.8 %anisotropic · dual curve
Specimen sRGB 236, 167, 92
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Strong, pinkish cream to pale cobalt-blue
Anisotropism
Very high, bright pinkish cream to very dark blue or black
Reflected colour
pinkish to blue

Crystallography

Crystal system
Hexagonal
Space group
P63/mmc
Cell parameters
a = 4.100(1) Å · c = 5.432(2) Å
Z
2
Morphology

rounded to anhedral inclusions

Type-locality form

Rounded to anhedral inclusions, to 75 µm.

Comment

on synthetic

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
78PtPlatinumPlatinum1195.084195.084
62.17%
50SnTinTin1118.710118.710
37.83%
Total313.794100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Pd
  • Sb
  • Bi
  • Te

Synonyms

  • Niggliiet

In other languages

German
Niggliit
Italian
Niggliite

Classification

Strunz
10th ed.

1.AG.60

  • 1ElementsClass
  • 1.AMetals and Intermetallic AlloysDivision
  • 1.AGPGE-metal alloysGroup
  • 1.AG.60NiggliiteSpecies
Dana
8th ed.

01.02.10.01

  • 01Native Elements and AlloysClass
  • 01.02Platinum Group Metals and AlloysType
  • 01.02.10— unnamed intermediate level —Group
  • 01.02.10.01NiggliiteSpecies
CIM

1.84

  • 1Elements and Alloys (including the arsenides, antimonides and bismuthides of Cu, Ag and Au)Class
  • 1.84— unnamed intermediate level —Group
  • 1.84NiggliiteSpecies

Literature, links & citation

Citations
  1. 1936Scholtz, D.L. (1936) The magmatic nickelferous ore deposits of East Griqualand and Pondoland. Transactions of the Geological Society of South Africa: 39: 184-186.
  2. 1937Scholtz (1937) Geol. Soc. South Africa, Transactions: 39: 81.
  3. 1938Foshag, W.F. (1938) New mineral names. American Mineralogist: 23: 64-64.
  4. 1944Palache, Charles, Berman, Harry, Frondel, Clifford (1944) The System of Mineralogy (7th ed.) Vol. 1 - Elements, Sulfides, Sulfosalts, Oxides. John Wiley and Sons, New York.
  5. 1971Fleischer, Michael (1971) New Mineral Names. American Mineralogist, 56 (1-2) 358-362
