Nybøite

NaNa2(Mg3Al2)(Si7Al)O22(OH)2
IMA status
  • Approved
IMA symbol
Nyb
IMA approved
1980
Also known as
  • Miyashiroite
  • Nyböit
  • Nyböita
  • +1 more

Where it forms, where it's found

Geological setting

The nybø eclogite pod

Type locality
Nybø eclogite pod
  1. Sørpollen
  2. Vågsøy
  3. Kinn
  4. Vestland
  5. Norway

61.9341°, 5.2171°

7recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105 – 6/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Colour
Grey-green · Blue-grey
Cleavage

Perfect on (110)

Density
3.12 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = Medium°
Refractive index
1.65 – 1.67
Surface relief
High
Principal indices
nα 1.65 · nγ 1.67
Pleochroism
Visible

Pale pink-violet; α colourless,β pale brownish-pink,and γ pale bluish-green.

Luminescence
Nonfluorescent
Notes

The β colour tends towards that characteristic of glaucophane and is quite distinctive.

Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 9.665(1) Å · b = 17.752(2) Å · c = 5.303(1) Å
Cell angles
β = 104.11(1) °
Ratio a:b:c
1 : 1.837 : 0.549
Unit cell volume
882.4 ų
Type-locality form

A thin section with an amphibole taken from sympletic-free areas in a single 16 cm thick compositionally-layered sample

Comment

From Oberti et al. (2003)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2415.999383.976
47.68%
14SiSiliconSilicon728.085196.595
24.41%
13AlAluminiumAluminium326.98280.946
10.05%
12MgMagnesiumMagnesium324.30572.915
9.05%
11NaSodiumSodium322.99068.970
8.56%
1HHydrogenHydrogen21.0082.016
0.25%
Total805.418100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Miyashiroite
  • Nybøiet
  • Nyböit
  • Nyböita

In other languages

German
Nybøit
Italian
nyboite · nybøite

Classification

Strunz
10th ed.

9.DE.25

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DEInosilicates with 2-periodic double chains, Si4O11; ClinoamphibolesGroup
  • 9.DE.25NybøiteSpecies
Dana
8th ed.

66.01.3c.11

  • 66Inosilicates Double-width, Unbranched Chains, (w=2)Class
  • 66.01Amphiboles - Mg-Fe-Mn-Li subgroupType
  • 66.01.3c— unnamed intermediate level —Group
  • 66.01.3c.11NybøiteSpecies
CIM

16.8.3

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.8Aluminosilicates of Mg and alkalisGroup
  • 16.8.3NybøiteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1981Ungaretti, Luciano, Smith, David C., Rossi, Giuseppe (1981) Crystal-chemistry by X-ray structure refinement and electron microprobe analysis of a series of sodic-calcic to alkali-amphiboles from the Nybö eclogite pod, Norway. Bulletin de Minéralogie, 104 (4) 400-412 doi:10.3406/bulmi.1981.7486DOI: 10.3406/bulmi.1981.7486
  2. 1992Pawley, Alison R. (1992) Experimental study of the compositions and stabilities of synthetic nyböite and nyböite-glaucophane amphiboles. European Journal of Mineralogy, 4 (1) 171-192 doi:10.1127/ejm/4/1/0171DOI: 10.1127/ejm/4/1/0171
  3. 1998Mandarino, Joseph A. (1998) The Second List of Additions and Corrections to the Glossary of Mineral Species (1995) - The Amphibole Group. The Mineralogical Record, 29 (3) 169-174
  4. 2001(2001) Nybøite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2003Oberti, R., Boiocchi, M., Smith, D. C. (2003) Fluoronyböite from Jianchang (Su-Lu, China) and nyböite from Nybö (Nordfjord, Norway): a petrological and crystal-chemical comparison of these two high-pressure amphiboles. Mineralogical Magazine, 67 (4) 769-782 doi:10.1180/0026461036740133DOI: 10.1180/0026461036740133
