Okanoganite-(Y)

(Y,REE,Ca,Na,Th)16(Fe3+,Ti)(Si,B,P)10(O,OH)38F10
IMA status
  • Approved
IMA symbol
Oka-Y
Discovered
1976
IMA approved
1979
Also known as
  • IMA1979-048
  • Okanoganiet-(Y)

Where it forms, where it's found

Geological setting

In miarolitic cavities in an alkaline arfvedsonite granite

Type locality
Washington Pass
  1. Golden Horn Batholith
  2. Okanogan County
  3. Washington
  4. USA

48.5242°, -120.6531°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Tan to pale pink

Colourless in thin fragments.

Streak
White
Density
4.31 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.74 – 1.753
Surface relief
High
Principal indices
nω 1.753 · nε 1.74
UV response
Does not fluoresce
Notes

Shows no dichroism

Michel-Lévy diagramhighlighted lineδ = 0.0130
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]130 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation130 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#86
Cell parameters
a = 10.7108(5) Å · c = 27.0398(11) Å
Z
3
Morphology

As pseudotetrahedral fourlings with twin plane {01-14}. Forms observed: c(0001) and s{10-4}.

Twinning

Common at TL as fourlings twinned on the composition plane {01-14} with the c face of each individual forming the faces of the pseudotetrahedra.

Type-locality form

As crystals up to 4 mm across. Both as isolated fourlings or as intergrown clusters.

Comment

Crystal system and cell parameters from Boiocchi (2004)

Crystal structure

Synonyms

  • IMA1979-048
  • Okanoganiet-(Y)

In other languages

German
IMA 1979-048 · Okanoganit-(Y)
Italian
Okanoganite- · Okanoganite-(Y)

Classification

Strunz
10th ed.

9.AJ.35

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AJNesosilicates with BO3 triangles and/or B[4], Be[4] tetrahedra, cornersharing with SiO4Group
  • 9.AJ.35Okanoganite-(Y)Species
Dana
8th ed.

54.02.04.03

  • 54Nesosilicates Borosilicates and Some BeryllosilicatesClass
  • 54.02Borosilicates and Some Beryllosilicates with B in [4] coordinationType
  • 54.02.04Howlite and related speciesGroup
  • 54.02.04.03Okanoganite-(Y)Species
CIM

17.5.21

  • 17Silicates Containing other AnionsClass
  • 17.5BorosilicatesGroup
  • 17.5.21Okanoganite-(Y)Species

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1980Boggs, Russell C. (1980) Okanoganite, a new rare-earth borofluorosilicate from the Golden Horn batholith, Okanogan County, Washington. American Mineralogist, 65 (11-12) 1138-1142
  2. 1996Grew, Edward S.; Anovitz, Lawrence M. - Eds. (1996) Boron - Mineralogy, Petrology and Geochemistry. Reviews in Mineralogy Vol. 33. Mineralogical Society of America p.862
  3. 2004Boiocchi, Massimo, Callegari, Athos, Ottolini, Luisa, Maras, Adriana (2004) The chemistry and crystal structure of okanoganite-(Y) and comparison with vicanite-(Ce) American Mineralogist, 89 (10) 1540-1545 doi:10.2138/am-2004-1024 DOI: 10.2138/am-2004-1024
  4. 2013(2013) Okanoganite-(Y). Handbook of Mineralogy. Mineralogical Society of America
