Okenite

Ca10Si18O46 · 18H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Oke
Discovered
1828
Also known as

Where it forms, where it's found

Geological setting

Amygdules in basalts

Type locality
Qullissat
  1. Disko Island
  2. Qeqertalik
  3. Greenland

70.0597°, -53.0081°

68recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White to slightly yellow · blue
Streak
White
Tenacity
elastic
Cleavage
Perfect

on (001)

Density
2.28 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 60° · 2V calc = 68 – 70°
Refractive index
1.512 – 1.542
Surface relief
Moderate
Principal indices
nα 1.512 – 1.532 · nβ 1.514 – 1.535 · nγ 1.515 – 1.542
Dispersion
none
Michel-Lévy diagramhighlighted lineδ = 0.0065
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]65 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation65 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 9.69(1) Å · b = 7.28(1) Å · c = 22.02(4) Å
Cell angles
α = 92.7 ° · β = 100.1 ° · γ = 110.9 °
Ratio a:b:c
1 : 0.751 : 2.272
Z
2
Morphology

Bladed crystals to laths. Commonly as fibers.

Twinning

About [010], composition plane (102), lamellar

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen6415.9991023.936
52.07%
14SiSiliconSilicon1828.085505.530
25.71%
20CaCalciumCalcium1040.078400.780
20.38%
1HHydrogenHydrogen361.00836.288
1.84%
Total1966.534100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Sr
  • Na
  • K

Synonyms

  • Bordit
  • Bordita
  • Bordite
  • Disclasit
  • Disclasita
  • Disclasite
  • Ockenite

In other languages

French
Bordite · Dysclasite · Okénite
German
Okenit
Spanish
Okenita
Italian
Okenite
Portuguese
Okenita
Japanese
オーケン石 · オケナイト
Russian
Окенит

Classification

Strunz
10th ed.

9.EA.40

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EASingle nets of tetrahedra with 4-, 5-, (6-), and 8-membered ringsGroup
  • 9.EA.40OkeniteSpecies
Dana
8th ed.

72.03.02.05

  • 72Phyllosilicates Two-dimensional Infinite Sheets with Other Than Six-membered RingsClass
  • 72.03Two-Dimensional Infinite Sheets with Other Than Six-Membered Rings with 3-, 4-, or 5-membered rings and 8-membered ringsType
  • 72.03.02Tobermorite group (5- & 8-membered rings)Group
  • 72.03.02.05OkeniteSpecies
CIM

14.5.18

  • 14Silicates not Containing AluminumClass
  • 14.5Silicates of CaGroup
  • 14.5.18OkeniteSpecies

Literature, links & citation

Citations
  1. American Society for Testing Materials. Card File of X-Ray Diffraction Data. Cards 2-0068, 2-0069, 2-0070.
  2. 1828von Kobell, F. (1828): Ueber den Ockenit, eine neue Mineralspecies. Archiv für die Gesammte Naturlehre, 14, 333-337.
  3. 1845Breithaupt, A. (1845) Ueber die Krystallisation des Okenits oder Dysklasits. Annalen der Physik und Chemie (Poggendorff): 64: 170-170.
  4. 1893Forster-Heddle, M. (1893) XVII. On Pectolite and Okenite from New Localities: the former with New Appearances. Transactions of the Geological Society of Glasgow: 9: 241-255.
  5. 1914Eackle, A.S., Rogers, A.F. (1914) Wilkeite, a new mineral of the apatite group, and okenite, its alteration product, from southern California. American Journal of Science, Series 4: 37(219): 262-267.
