Organovaite-Mn

K2MnNb4(Si4O12)2O4 · 5-7H2O
IMA status
  • Approved
IMA symbol
Org-Mn
IMA approved
2000
Also known as
  • IMA2000-031
  • Organovaiet-Mn

Where it forms, where it's found

Geological setting

Ultrabasic massif.

Type locality
Karnasurt Mountain
  1. Lovozersky District
  2. Murmansk Oblast
  3. Russia

67.8808°, 34.6817°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Pinkish in various shades · rose-brown · yellow-brown
Streak
White
Tenacity
brittle
Cleavage
None Observed
Fracture
Irregular/Uneven
Density
2.88 g/cm³

Optical

Optical type
Biaxial (+) · 2V calc = 38°
Refractive index
1.683 – 1.775
Surface relief
High
Principal indices
nα 1.683 · nβ 1.692 · nγ 1.775
Pleochroism
Visible

X, Z: colourless Y: light brown

Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0920
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]920 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation920 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 14.551 Å · b = 14.001 Å · c = 15.702 Å
Cell angles
β = 117.584 °
Ratio a:b:c
1 : 0.962 : 1.079
Z
2
Type-locality form

Stubby prismatic crystals up to 0.3 mm, and pseudomorphs after vuonnemite crystals up to 4 cm.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3315.999527.967
41.65%
41NbNiobiumNiobium492.906371.624
29.32%
14SiSiliconSilicon828.085224.680
17.73%
19KPotassiumPotassium239.09878.196
6.17%
25MnManganeseManganese154.93854.938
4.33%
1HHydrogenHydrogen101.00810.080
0.80%
Total1267.485100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2000-031
  • Organovaiet-Mn

In other languages

German
IMA 2000-031 · Organovait-Mn
Italian
organovaite-Mn

Classification

Strunz
10th ed.

9.CE.30g

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CE[Si4O12]8- 4-membered single rings (vierer-Einfachringe), without insular complex anionsGroup
  • 9.CE.30gOrganovaite-MnSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 2001Chukanov, N. V., Pekov, I. V., Zadov, A. E., Krivovichev, S. V., Berns, P. C., Schneider, Y. (2001) Organovaite-Mn, K2Mn(Nb,Ti)4(Si4O12)2(O,OH)4·6H2O, a new labuntsovite group mineral from Lovozero Massif, Kola Peninsula. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva, 130 (2) 46-53
  2. 2002Chukanov, Nikita V., Pekov, Igor V., Khomyakov, Alexander P. (2002) Recommended nomenclature for labuntsovite-group minerals. European Journal of Mineralogy, 14 (1) 165-173 doi:10.1127/0935-1221/2002/0014-0165 DOI: 10.1127/0935-1221/2002/0014-0165
  3. 2002Jambor, John L., Roberts, Andrew C. (2002) New mineral names. American Mineralogist, 87 (11) 1731-1735
  4. 2021(2021) Organovaite-Mn. Handbook of Mineralogy. Mineralogical Society of America
