Otjisumeite

PbGe4O9
IMA status
  • Approved
IMA symbol
Otj
Discovered
1981
Also known as
  • IMA1978-080
  • Otjisumeiet

Where it forms, where it's found

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
White · colorless
Streak
White

Optical

Optical type
Biaxial (+) · 2V measured = 20° · 2V calc = 36°
Refractive index
1.92 – 1.943
Surface relief
Very high
Principal indices
nα 1.92 · nβ 1.922 · nγ 1.943
Dispersion
none
Michel-Lévy diagramhighlighted lineδ = 0.0230
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]230 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation230 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Cell parameters
a = 6.94 Å · b = 6.58 Å · c = 9.27 Å
Cell angles
α = 102.94 ° · β = 103.05 ° · γ = 114.77 °
Ratio a:b:c
1 : 0.948 : 1.336
Morphology

Pseudohexagonal crystals Elongated parallel to the c axis, columnar to fibrous habit; usually form radiating aggregates.

Comment

Pseudo-hexagonal.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
32GeGermaniumGermanium472.630290.520
45.27%
82PbLeadLead1207.200207.200
32.29%
8OOxygenOxygen915.999143.991
22.44%
Total641.711100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1978-080
  • Otjisumeiet

In other languages

German
IMA 1978-080 · Otjisumeit
Italian
Otjisumeite

Classification

Strunz
10th ed.

9.J0.15

  • 9SilicatesClass
  • 9.JGermanatesDivision
  • 9.J0— unnamed intermediate level —Group
  • 9.J0.15OtjisumeiteSpecies
Dana
8th ed.

07.10.03.01

  • 07Multiple OxidesClass
  • 07.10AB4X9Type
  • 07.10.03— unnamed intermediate level —Group
  • 07.10.03.01OtjisumeiteSpecies
CIM

7.11.18

  • 7Oxides and HydroxidesClass
  • 7.11Oxides of Sn and PbGroup
  • 7.11.18OtjisumeiteSpecies

Literature, links & citation

Citations
  1. 1981Keller, Paul, Hess, Heinz, Dunn, Pete J. (1981) Otjisumeit, PbGe4O9, ein neues Mineral aus Tsumeb, Namibia [Otjisumeite, PbGe4O9, a new mineral from Tsumeb, Namibia]. Neues Jahrbuch für Mineralogie - Monatshefte, 1981. 49-55
  2. 1984Shashkov, A.Yu., Rannev, N.V., Venevtsev, Yu.N. (1984) Atomic structure of crystals of α-(PbGe4O9), BaGe4O9, and Pb2/3Sr1/3Ge4O9 and features of the coordination of germanium atoms in framework tetragermanates. Soviet Journal of Coordination Chemistry: 10: 1420-1426.
  3. 1987Hawthorne, Frank C., Jambor, John L., Bladh, Kenneth W., Burke, Ernst A. J., Grice, Joel D., Phillips, Don, Roberts, Andrew C., Schedler, Robert A., E., James (1987) New mineral names. American Mineralogist, 72 (9-10) 1023-1028
  4. 2005(2005) Otjisumeite. Handbook of Mineralogy. Mineralogical Society of America
