Oulankaite

Pd5Cu4SnTe2S2
IMA status
  • Approved
IMA symbol
Oul
IMA approved
1990
Also known as
  • IMA1990-055
  • Oulankaiet
  • Oulongaite

Where it forms, where it's found

Geological setting

In pegmatoidal pyroxenite hosted in microgabbronorite.

Type locality
Lukkulaisvaara ultrabasic Massif (Lukkulaisvaara pluton
  1. Lukkulaisvaara layered intrusion)
  2. Olanga River (Oulanka River)
  3. Oulanka plutonic complex
  4. Loukhsky District
  5. Republic of Karelia
  6. Russia
1recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Metallic
Transparency
Opaque
Density
10.27 g/cm³

Optical

Pleochroism
Visible

Purplish pink, creamy pink or grayish cream tints.

Anisotropism
strong from yellowish-white to bluish-grey
Bireflectance
strongly bireflectant
Tropism
Anisotropic
Reflectance R%
(33.0,31.5,24.3,22.0) 400, (38.4,34.5,27.0,23.2) 440, (41.6,36.2,29.1,23.5) 470, (44.9,38.2,31.8,25.3) 500, (48.7,41.0,35.2,29.5) 546, (49.9,41.8,35.9,30.1) 560, (51.7,43.1,37.1,30.8) 589, (53.1,44.0,40.7,34.3) 620, (54.0,44.6,39.4,33.8) 650, (54.2,44.8,39.1,33.6) 680, (54.3,45.0,38.5,33.0) 700

Crystallography

Crystal system
Tetragonal
Cell parameters
a = 9.044(3) Å · c = 4.937(3) Å
Z
2
Morphology

platy grains to 0.2 mm, with characteristic fine twins. Occurs as inclusions in chalcopyrite.

Twinning

platy twins

Type-locality form

platy subhedral to euhedral inclusions in chalcopyrite

Comment

Tetragonal (based on XRD pattern). Point Group: n.d.; Space Group: n.d.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
46PdPalladiumPalladium5106.420532.100
43.46%
52TeTelluriumTellurium2127.600255.200
20.84%
29CuCopperCopper463.546254.184
20.76%
50SnTinTin1118.710118.710
9.70%
16SSulfurSulfur232.06064.120
5.24%
Total1224.314100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1990-055
  • Oulankaiet
  • Oulongaite

In other languages

German
IMA 1990-055 · Oulankait
Italian
Oulankaite

Classification

Strunz
10th ed.

2.BC.40

  • 2Sulfides and SulfosaltsClass
  • 2.BMetal Sulfides, M: S > 1: 1 (mainly 2: 1)Division
  • 2.BCWith Rh, Pd, Pt, etc.Group
  • 2.BC.40OulankaiteSpecies

Literature, links & citation

Citations
  1. 1996Mandarino, Joseph A. (1996) Abstracts of New Mineral Descriptions. The Mineralogical Record, 27 (6) 463-466
  2. 1996Barkov, Andrew Yu., Men’Shikov, Yurii P., Begizov, Victor D., Lednev, Andrew I. (1996) Oulankaite, a new platinum-group mineral from the Lukkulaisvaara layered intrusion, northern Karelia, Russia. European Journal of Mineralogy, 8 (2) 311-316 doi:10.1127/ejm/8/2/0311DOI: 10.1127/ejm/8/2/0311
  3. 2004Barkov, A. Y., Fleet, M. E., Martin, R. F., Tarkian, M. (2004) Compositional variations of oulankaite and a new series of argentian oulankaite from the Lukkulaisvaara layered intrusion, northern Russian Karelia. The Canadian Mineralogist, 42 (2) 439-453 doi:10.2113/gscanmin.42.2.439 DOI: 10.2113/gscanmin.42.2.439
  4. 2005Jambor, John L., Roberts, Andrew C. (2005) New Mineral Names. American Mineralogist, 90 (1) 271-275 doi:10.2138/am.2005.429DOI: 10.2138/am.2005.429
  5. 2021(2021) Oulankaite. Handbook of Mineralogy. Mineralogical Society of America
