Oursinite

Co(UO2)2(SiO3OH)2 · 6H2O
IMA status
  • Approved
IMA symbol
Osn
IMA approved
1982
Also known as
  • IMA1982-051

Where it forms, where it's found

Geological setting

Uranium deposit; brecciated dolomite.

Type locality
Shinkolobwe Mine
  1. Shinkolobwe
  2. Kambove Territory
  3. Haut-Katanga
  4. DR Congo

-11.0486°, 26.5508°

2recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789103 – 3.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Pale yellow
Cleavage
Distinct/Good

on {hk0}

Density
3.674 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 76° · 2V calc = 76°
Refractive index
1.624 – 1.65
Surface relief
Moderate
Principal indices
nα 1.624 · nβ 1.64 · nγ 1.65
Dispersion
weak
Michel-Lévy diagramhighlighted lineδ = 0.0260
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]260 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation260 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#49
Cell parameters
a = 7.0457(4) Å · b = 17.5445(8) Å · c = 12.7231(2) Å
Ratio a:b:c
1 : 2.490 : 1.806
Z
4
Morphology

Radiating aggregates of acicular crystals to 1mm.

Type-locality form

Radial aggregates of pale yellow acicular crystals, with maximum dimensions 1 x 0.02 x 0.02 mm.

Comment

Cell parameters from Plášil (2018) with R1=2.03%.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
53.29%
8OOxygenOxygen1815.999287.982
32.24%
27CoCobaltCobalt158.93358.933
6.60%
14SiSiliconSilicon228.08556.170
6.29%
1HHydrogenHydrogen141.00814.112
1.58%
Total893.255100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ni

Synonyms

  • IMA1982-051

In other languages

German
IMA 1982-051 · Oursinit
Italian
Oursinite

Classification

Strunz
10th ed.

9.AK.10

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AKUranyl neso- and polysilicatesGroup
  • 9.AK.10OursiniteSpecies
Dana
8th ed.

53.03.01.07

  • 53Nesosilicates Insular Sio4 Groups and Other Anions or Complex CationsClass
  • 53.03Insular SiO4 Groups and Other Anions of Complex Cations with (UO2)Type
  • 53.03.01Uranophane groupGroup
  • 53.03.01.07OursiniteSpecies
CIM

14.16.19

  • 14Silicates not Containing AluminumClass
  • 14.16Silicates of UGroup
  • 14.16.19OursiniteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1983Deliens, Michel, Piret, Paul (1983) L'oursinite (Co0,86Mg0,10Ni0,04)O.2UO3. 2SiO2.6H2O, nouveau minéral de Shinkolobwe, Shaba, Zaïre. Bulletin de Minéralogie, 106 (3) 305-308 doi:10.3406/bulmi.1983.7710 DOI: 10.3406/bulmi.1983.7710
  2. 1984Dunn, Pete J., Chao, George Y., Grice, Joel D., Ferraiolo, James A., Fleischer, Michael, Pabst, Adolf, Zilczer, Janet A. (1984) New mineral names. American Mineralogist, 69 (5-6) 565-569
  3. 2001(2001) Oursinite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2005Burns, Peter C. (2005) U6+ minerals and inorganic compounds: insights into an expanded structural hierarchy of crystal structures. The Canadian Mineralogist, 43 (6) 1839-1894 doi:10.2113/gscanmin.43.6.1839 DOI: 10.2113/gscanmin.43.6.1839
  5. 2006Kubatko, K.-A.; Burns, P.C. (2006) A novel arrangement of silicate tetrahedra in the uranyl silicate sheet of oursinite, (Co0.8Mg0.2)[(UO2)(SiO3OH)]2(H2O)6. American Mineralogist, 91 (2). 333-336 doi:10.2138/am.2006.1613 DOI: 10.2138/am.2006.1613
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Oursinite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/oursinite-3047},
  note      = {Accessed 2026-05-11}
}
