Oxammite

(NH4)2(C2O4) · H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Oxa
Discovered
1870
Also known as
  • Guanapit
  • Guañapite
  • Oxammiet

Where it forms, where it's found

Geological setting

Bird guano deposit.

Bird and bat guano deposits

Type locality
Guañape Islands
  1. Virù Province
  2. La Libertad
  3. Peru

-8.5349°, -78.9627°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Opaque
Colour
Colourless to pale yellow · colourless in transmitted light.
Streak
White
Cleavage
Distinct/Good

On (001), distinct. Frondel (1950) describes the cleavage as perfect.

Density
1.5 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 62° · 2V calc = 62°
Refractive index
1.438 – 1.595
Surface relief
Moderate
Principal indices
nα 1.438 · nβ 1.547 · nγ 1.595
Dispersion
dispersion not observed
Notes

X = c, Y = a, Z = b. The optics of synthetic material are covered in Winchell (1951)

Michel-Lévy diagramhighlighted lineδ = 0.1570
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1570 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1570 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#43
Cell parameters
a = 8.035 Å · b = 10.32 Å · c = 3.801 Å
Ratio a:b:c
1 : 1.284 : 0.473
Z
2
Morphology

Crystals rare; commonly occurs as lamellar or powdery masses. Artificial crystals are spenoidal in form.

Type-locality form

Very delicate but perfect crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen515.99979.995
56.29%
7NNitrogenNitrogen214.00728.014
19.71%
6CCarbonCarbon212.01124.022
16.91%
1HHydrogenHydrogen101.00810.080
7.09%
Total142.111100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Guanapit
  • Guañapite
  • Oxammiet

In other languages

French
Oxammite
German
Guanapit · Oxammit
Spanish
Oxamita
Italian
Oxammite

Classification

Strunz
10th ed.

10.AB.55

  • 10Organic CompoundsClass
  • 10.ASalts of organic acidsDivision
  • 10.ABOxalatesGroup
  • 10.AB.55OxammiteSpecies
Dana
8th ed.

50.01.05

  • 50Organic CompoundsClass
  • 50.01OxalatesType
  • 50.01.05— unnamed intermediate level —Group
  • 50.01.05OxammiteSpecies
CIM

31.1.1

  • 31Oxalates, Citrates, Mellitates and AcetatesClass
  • 31.1OxalatesGroup
  • 31.1.1OxammiteSpecies

Literature, links & citation

Citations
  1. 1867Brio (1867) Konigliche Akademie der Wissenschaften, Vienna, Sitzber.: 55: 870.
  2. 1870Shepard, C.U. (1870) Notice of the Guanape Island guano. The Rural Carolinian: 1: 469-471.
  3. 1875Tanner (1875) Chemical News and Journal of Industrial Science, London: 32: 162.
  4. 1892Dana, Edward Salisbury; Dana, James Dwight (1892) A System of Mineralogy (6th ed.). John Wiley & Sons, Inc.
  5. 1910Groth, P. (1910) Chemische Krystallographie Vol. 3. Wilhem Engelmann.
