Oxycalciopyrochlore

Ca2Nb2O6O
IMA status
  • Approved
IMA symbol
Ocpcl
IMA approved
1978

Where it forms, where it's found

Geological setting

In a pegmatite cross-cutting a serpentinite.

Type locality
Věžná I pegmatite
  1. Věžná
  2. Žďár nad Sázavou District
  3. Vysočina Region
  4. Czech Republic

49.4478°, 16.2747°

18recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Brownish-black

It turns pale orange after heating at 700°C for 1 h in air.

Streak
Creamy-white
Tenacity
brittle
Density
5.30 g/cm³

Optical

Optical type
Isotropic
Pleochroism

n = >1.78.

Optical colour
Medium gray
Tropism
Isotropic
Isotropy testPPL ↔ XPL diagnostic
PPL intrinsic colour; no change on stage rotation
XPL extinct at every orientation

Crystallography

Crystal system
Isometric
Space group
Fd-3m
Cell parameters
a = 10.35 Å
Unit cell volume
1110.6 ų
Z
8
Morphology

Discrete octahedra, or as granular aggregates.

Type-locality form

Discrete octahedra, or granular aggregates veining and replacing partly disordered columbite and niobian rutile.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
41NbNiobiumNiobium292.906185.812
49.16%
8OOxygenOxygen715.999111.993
29.63%
20CaCalciumCalcium240.07880.156
21.21%
Total377.961100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

German
Oxycalciopyrochlor
Italian
ossicalciopirocloro · Stibiobetafite

Classification

Strunz
10th ed.

4.DH.15

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DHWith large (+- medium-sized) cations; sheets of edge-sharing octahedraGroup
  • 4.DH.15OxycalciopyrochloreSpecies

Group, growth & confusion

Literature, links & citation

Citations
  1. 1979Černý, P., Hawthorne, F.C., Laflamme, J.H.G., and Hinthorne, J.R. (1979) Stibiobetafite, a new member of the pyrochlore group from Venzá, Czechoslovakia. The Canadian Mineralogist: 17: 583-588.
  2. 2010Atencio, D., Andrade, M. B., Christy, A. G., Giere, R., Kartashov, P. M. (2010) The pyrochlore supergroup of minerals: nomenclature. The Canadian Mineralogist, 48 (3) 673-698 doi:10.3749/canmin.48.3.673 DOI: 10.3749/canmin.48.3.673
  3. 2013Christy, A. G., Atencio, D. (2013) Clarification of status of species in the pyrochlore supergroup. Mineralogical Magazine, 77 (1) 13-20 doi:10.1180/minmag.2013.077.1.02 DOI: 10.1180/minmag.2013.077.1.02
  4. 2020(2020) Oxycalciopyrochlore. Handbook of Mineralogy. Mineralogical Society of America
