Painite

CaZrAl9O15(BO3)
IMA status
  • Approved
  • Grandfathered
IMA symbol
Pai
Discovered
1956

Where it forms, where it's found

Geological setting

Gem gravels.

Type locality
Ohngaing
  1. Mogok Valley
  2. Mogok Township
  3. Pyin-Oo-Lwin District
  4. Mandalay Region
  5. Myanmar

22.9333°, 96.4967°

8recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789108/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Red · brownish · orange-red
Density
4.01 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.7875 – 1.8159
Surface relief
Very high
Principal indices
nω 1.8159 · nε 1.7875
Pleochroism
Strong

Ruby-red // to [0001]; pale brownish orange or pale red-orange perpendicular to [0001].

Michel-Lévy diagramhighlighted lineδ = 0.0284
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]284 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation284 nm
Order1st order
XPL colour

Crystallography

Crystal system
Hexagonal
Space group
#108
Cell parameters
a = 8.724(1) Å · c = 8.464(2) Å
Morphology

Elongate crystals.

Type-locality form

Single crystal.

Comment

Data from Armbruster et al. (2004); previously assumed to have space group P63.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
42.79%
13AlAluminiumAluminium926.982242.838
36.09%
40ZrZirconiumZirconium191.22491.224
13.56%
20CaCalciumCalcium140.07840.078
5.95%
5BBoronBoron110.81010.810
1.61%
Total672.932100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

French
Painite
German
Painit
Spanish
Painita
Italian
Painite
Portuguese
painita · Painite
Japanese
ペイン石
Chinese
铝硼锆钙石
Russian
пейнит
Arabic
بيانيت

Classification

Strunz
10th ed.

6.AB.85

  • 6BoratesClass
  • 6.AMonoboratesDivision
  • 6.ABBO3, with additional anions; 1(D) + OH, etc.Group
  • 6.AB.85PainiteSpecies
Dana
8th ed.

07.05.02.01

  • 07Multiple OxidesClass
  • 07.05(AB)2X3Type
  • 07.05.02— unnamed intermediate level —Group
  • 07.05.02.01PainiteSpecies
CIM

7.10.3

  • 7Oxides and HydroxidesClass
  • 7.10Oxides of Zr and ThGroup
  • 7.10.3PainiteSpecies

Literature, links & citation

Citations
  1. 1957Fleischer, M. (1957) New mineral names. American Mineralogist, 42 (7-8) 580-586
  2. 1957Claringbull, G. F., Hey, Max H., Payne, C. J. (1957) Painite, a new mineral from Mogok, Burma. Mineralogical Magazine and Journal of the Mineralogical Society, 31 (236) 420-425 doi:10.1180/minmag.1957.031.236.11 DOI: 10.1180/minmag.1957.031.236.11
  3. 1976Moore, Paul Brian, Araki, Takaharu (1976) Painite, CaZrB[Al9O18]: Its crystal structure and relation to jeremejevite, B5[◻3Al6(OH)3O15], and fluoborite, B3[Mg9(F,OH)9O9]. American Mineralogist, 61 (1-2) 88-94
  4. 1980McWhirter, Norris - Ed. (1980) Guinnes Book of World Records - 1981 Edition. Sterling Publishing Co., Inc.
  5. 1986Shigley, James E., Kampf, Anthony R., Rossman, George R. (1986) New data on painite. Mineralogical Magazine, 50 (356) 267-270 doi:10.1180/minmag.1986.050.356.09 DOI: 10.1180/minmag.1986.050.356.09
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Painite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/painite-3063},
  note      = {Accessed 2026-05-11}
}
