Paramendozavilite

NaAl4Fe7(PO4)5(PMo12O40)(OH)16 · 56H2O
IMA status
  • Approved
IMA symbol
Pmdz
Discovered
1986
Also known as
  • IMA1982-010
  • Paramendozaviliet

Where it forms, where it's found

Type locality
San Judas Mine
  1. Cumobabi
  2. El Verde Mining District
  3. Cumpas Municipality
  4. Sonora
  5. Mexico

29.8694°, -109.9627°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Pale yellow
Streak
Very pale yellow
Cleavage
Perfect

one perfect cleavage

Density
3.35 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 60° · 2V calc = 64.9°
Refractive index
1.686 – 1.72
Surface relief
High
Principal indices
nα 1.686 · nβ 1.710 · nγ 1.720
Pleochroism
Visible

Pale yellow, Z > Y > X

Dispersion
r > v
Michel-Lévy diagramhighlighted lineδ = 0.0340
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]340 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation340 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 10.963(2) Å · b = 25.881(3) Å · c = 15.434(2) Å
Cell angles
β = 110.73(1) °
Ratio a:b:c
1 : 2.361 : 1.408
Unit cell volume
4095.8 ų
Z
2
Twinning

Crystals are mostly twinned. Polysynthetic, observed optically parallel to cleavage

Type-locality form

coatings

Comment

Point Group: n.d. ; Space Group: n.d.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen13215.9992111.868
51.51%
42MoMolybdenumMolybdenum1295.9501151.400
28.08%
26FeIronIron755.845390.915
9.54%
15PPhosphorusPhosphorus630.974185.844
4.53%
1HHydrogenHydrogen1281.008129.024
3.15%
13AlAluminiumAluminium426.982107.928
2.63%
11NaSodiumSodium122.99022.990
0.56%
Total4099.969100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-010
  • Paramendozaviliet

In other languages

German
IMA 1982-010 · Paramendozavilit
Italian
Paramendozavilite

Classification

Strunz
10th ed.

7.GB.45

  • 7SulfatesClass
  • 7.GMolybdates, Wolframates and NiobatesDivision
  • 7.GBWith additional anions and/or H2OGroup
  • 7.GB.45ParamendozaviliteSpecies
Dana
8th ed.

49.04.06.01

  • 49Hydrated Molybdates and TungstatesClass
  • 49.04Compound Molybdates and TungstatesType
  • 49.04.06— unnamed intermediate level —Group
  • 49.04.06.01ParamendozaviliteSpecies
CIM

22.5.7

  • 22Phosphates, Arsenates or Vanadates with other AnionsClass
  • 22.5Phosphates, arsenates or vanadates with chromate, molybdate, niobate or tantalateGroup
  • 22.5.7ParamendozaviliteSpecies

Literature, links & citation

Citations
  1. 1986Williams, S.A. (1986) Mendozavilite and paramendozavilite, two new minerals from Cumobabi, Sonora. Boletín de Mineralogía:, 2. 13-19
  2. 1988Hawthorne, Frank C., Burke, Ernst A. J., Ercit, T. Scott, Grew, Edward S., Grice, Joel D., Jambor, John L., Puziewicz, Jacek, Roberts, Andrew C., Vanko, David A. (1988) New Mineral Names. American Mineralogist, 73 (1-2) 189-199
  3. 2012Kampf, A. R., Mills, S. J., Rumsey, M. S., Dini, M., Birch, W. D., Spratt, J., Pluth, J. J., Steele, I. M., Jenkins, R. A., Pinch, W. W. (2012) The heteropolymolybdate family: structural relations, nomenclature scheme and new species. Mineralogical Magazine, 76 (5) 1175-1207 doi:10.1180/minmag.2012.076.5.09DOI: 10.1180/minmag.2012.076.5.09
  4. 2021(2021) Paramendozavilite. Handbook of Mineralogy. Mineralogical Society of America
