Paravinogradovite

(Na,◻)2(Ti4+,Fe3+)4(Si2O6)2(Si3AlO10)(OH)4 · H2O
IMA status
  • Approved
IMA symbol
Pvgd
Discovered
1986
IMA approved
2002
Also known as
  • IMA2002-033
  • Paravinogradoviet

Where it forms, where it's found

Geological setting

In vugs of an albite rich pegmatite lens.

Type locality
Northeast slope
  1. Kukisvumchorr Mt
  2. Murmansk Oblast
  3. Russia

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Colourless to white
Streak
White
Tenacity
brittle
Cleavage
Perfect

Perfect on (001) and indistinct (010)

Fracture
Splintery
Density
2.77 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 64° · 2V calc = 64°
Refractive index
1.707 – 1.755
Surface relief
High
Principal indices
nα 1.707 · nβ 1.741 · nγ 1.755
Pleochroism
Non-pleochroic
Dispersion
r > v
Extinction
b ≈ Z, a ∧ X = 30°
UV response
Weak yellow-green fluorescence in short-wave UV light.
Notes

Negative elongation

Michel-Lévy diagramhighlighted lineδ = 0.0480
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]480 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation480 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#1
Cell parameters
a = 5.253 Å · b = 8.741 Å · c = 12.95 Å
Cell angles
α = 70.46 ° · β = 78.47 ° · γ = 89.93 °
Ratio a:b:c
1 : 1.664 : 2.465
Morphology

Slender to acicular prismatic crystals.

Type-locality form

Fan-shaped aggregates of slender to acicular prismatic crystals to 10 mm, pseudomorphing vinogradovite.

Crystal structure

Synonyms

  • IMA2002-033
  • Paravinogradoviet

In other languages

German
IMA 2002-033 · Paravinogradovit
Italian
Paravinogradovite

Classification

Strunz
10th ed.

9.DB.25

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DBInosilicates with 2-periodic single chains, Si2O6; Pyroxene-related mineralsGroup
  • 9.DB.25ParavinogradoviteSpecies

Literature, links & citation

Citations
  1. 1990Khomyakov, A. P. (1990) Mineralogy of Hyperagpaitic Alkaline rocks. Nauka, Moscow, Russia (in Russian)[as a vinogradovite-like mineral]
  2. 1995Khomyakov, A. P. (1995) Mineralogy of Hyperagpaitic Alkaline Rocks. Clarendon Press. 223 pp.
  3. 2003Khomyakov, A. P., Kulikova, I. E., Sokolova, E., Hawthorne, F. C., Kartashov, P. M. (2003) Paravinogradovite, (Na,◻)2[(Ti4+,Fe3+)4{Si2O6}2{Si3AlO10}(OH)4]H2O, a new mineral species from the Khibina Alkaline Massif, Kola Peninsula, Russia: description and crystal structure. The Canadian Mineralogist, 41 (4) 989-1002 doi:10.2113/gscanmin.41.4.989 DOI: 10.2113/gscanmin.41.4.989
  4. 2004Jambor, J.L., Roberts, A.C. (2004) New Mineral Names. American Mineralogist, 89, 894–897.
  5. 2021(2021) Paravinogradovite. Handbook of Mineralogy. Mineralogical Society of America
