Pellyite

Ba2CaFe2+2Si6O17
IMA status
  • Approved
IMA symbol
Ply
Discovered
1971
Also known as
  • IMA1970-035
  • Pellyiet

Where it forms, where it's found

Geological setting

Occurs in a contact metasomatic deposit adjacent to a porphyritic quartz monzonite stock; as a massive crystalline constituent of skarns which have developed in original limestone bodies adjacent to the igneous contact.

Type locality
Gun claim
  1. Wilson Lake
  2. Itsi Mountain
  3. Watson Lake mining district
  4. Yukon
  5. Canada

62.8472°, -130.0142°

6recorded occurrences
Source · OpenStreetMap

Varieties

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
colorless to pale yellow
Cleavage
Poor/Indistinct

Prismatic, poorly developed

Fracture
Conchoidal
Density
3.51 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 53 – 61° · 2V calc = 72°
Refractive index
1.627 – 1.649
Surface relief
Moderate
Principal indices
nα 1.627 – 1.643 · nβ 1.629 – 1.645 · nγ 1.641 – 1.649
Dispersion
Very strong, r > v.
Michel-Lévy diagramhighlighted lineδ = 0.0100
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]100 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation100 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 14.209(6) Å · b = 15.677(4) Å · c = 7.151(2) Å
Ratio a:b:c
1 : 1.103 : 0.503
Z
4
Type-locality form

Grains to 2 mm.

Comment

Space Group: Amma

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium2137.327274.654
31.68%
8OOxygenOxygen1715.999271.983
31.38%
14SiSiliconSilicon628.085168.510
19.44%
26FeIronIron255.845111.690
12.88%
20CaCalciumCalcium140.07840.078
4.62%
Total866.915100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Mn
  • Zn

Synonyms

  • IMA1970-035
  • Pellyiet

In other languages

German
IMA 1970-035 · Pellyit
Italian
Pellyite

Classification

Strunz
10th ed.

9.DO.10

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DOInosilicates with 7-, 8-, 10-, 12- and 14-periodic chainsGroup
  • 9.DO.10PellyiteSpecies
Dana
8th ed.

78.06.03.01

  • 78Unclassified SilicatesClass
  • 78.06Unclassified silicates possible tectosilicatesType
  • 78.06.03— unnamed intermediate level —Group
  • 78.06.03.01PellyiteSpecies
CIM

14.7.9

  • 14Silicates not Containing AluminumClass
  • 14.7Silicates of Ba, Sr and ZnGroup
  • 14.7.9PellyiteSpecies

Literature, links & citation

Citations
  1. 1972Montgomery, J. H.; Thompson, R. M.; Meagher, E. P. (1972) Pellyite: a new barium silicate mineral from the Yukon Territory. The Canadian Mineralogist, 11 (2). 444-447
  2. 1976Meagher, E. P. (1976) The atomic arrangement of pellyite: Ba2Ca(Fe,Mg)2Si6O17. American Mineralogist, 61 (1-2) 67-73
  3. 1984Pabst, A.; Harris, J. (1984) Pellyite: new localities and new data. The Canadian Mineralogist, 22 (4). 653-658
  4. 2001(2001) Pellyite. Handbook of Mineralogy. Mineralogical Society of America
