Plumbophyllite

Pb2Si4O10 · H2O
IMA status
  • Approved
IMA symbol
Pbp
Discovered
2000
IMA approved
2008
Also known as
  • IMA2008-025
  • Plumbophylliet

Where it forms, where it's found

Geological setting

Oxidation zone

Type locality
Blue Bell Mine
  1. Zzyzx
  2. Soda Mountains
  3. Silver Lake Mining District
  4. San Bernardino County
  5. California
  6. USA

35.2419°, -116.2047°

4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
pale blue to very light blue-green
Streak
white
Tenacity
brittle
Cleavage
Perfect

(100)

Fracture
Splintery
Density
3.96 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 66° · 2V calc = 66.5°
Refractive index
1.674 – 1.708
Surface relief
High
Principal indices
nα 1.674 · nβ 1.684 · nγ 1.708
Pleochroism
Non-pleochroic
Dispersion
Strong r > v dispersion
UV response
None
Michel-Lévy diagramhighlighted lineδ = 0.0340
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]340 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation340 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#63
Cell parameters
a = 13.2083 Å · b = 9.7832 Å · c = 8.6545 Å
Ratio a:b:c
1 : 0.741 : 0.655
Morphology

Plumbophyllite forms prismatic crystals, elongate on c, with wedge-shaped terminations

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
58.80%
8OOxygenOxygen1115.999175.989
24.97%
14SiSiliconSilicon428.085112.340
15.94%
1HHydrogenHydrogen21.0082.016
0.29%
Total704.745100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2008-025
  • Plumbophylliet

In other languages

German
IMA 2008-025 · Plumbophyllit
Italian
plumbophyllite

Classification

Strunz
10th ed.

9.EA.85

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EASingle nets of tetrahedra with 4-, 5-, (6-), and 8-membered ringsGroup
  • 9.EA.85PlumbophylliteSpecies

Literature, links & citation

Citations
  1. 2009Kampf, A. R., Rossman, G. R., Housley, R. M. (2009) Plumbophyllite, a new species from the Blue Bell claims near Baker, San Bernardino County, California. American Mineralogist, 94 (8) 1198-1204 doi:10.2138/am.2009.3156 DOI: 10.2138/am.2009.3156
  2. 2010minerals.gps.caltech.edu (n.d.) http://minerals.gps.caltech.edu/Manuscripts/2009/Plumbophyllite/Index.html
  3. 2014Frost, Ray L., López, Andrés, Xi, Yunfei, Scholz, Ricardo, Lana, Cristiano (2014) A vibrational spectroscopic study of the silicate mineral plumbophyllite Pb2Si4O10⋅H2O. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 128. 665-670 doi:10.1016/j.saa.2014.02.181DOI: 10.1016/j.saa.2014.02.181
  4. 2021(2021) Plumbophyllite. Handbook of Mineralogy. Mineralogical Society of America
