Poldervaartite

Ca(Ca,Mn)(SiO3OH)(OH)
IMA status
  • Approved
IMA symbol
Pdv
IMA approved
1992
Also known as
  • IMA1992-012
  • Poldervaartiet

Where it forms, where it's found

Geological setting

Alteration of low-grade Mn-rich metasediments by hydrothermal fluids rich in Ca, Si02, and C02.

In massive manganese ore.

Type locality
Wessels Mine
  1. Joe Morolong Local Municipality
  2. John Taolo Gaetsewe District Municipality
  3. Northern Cape
  4. South Africa

-27.1135°, 22.8544°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
colourless · milky white · pink-white
Streak
white
Tenacity
very brittle
Cleavage
None Observed
Density
2.91 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 63 – 65° · 2V calc = 64°
Refractive index
1.634 – 1.656
Surface relief
Moderate
Principal indices
nα 1.634 · nβ 1.64 · nγ 1.656
Pleochroism
Weak

X= colorless Y= light gray Z= bluish gray

Dispersion
r < v weak
UV response
Deep red in SW
Michel-Lévy diagramhighlighted lineδ = 0.0220
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]220 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation220 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#61
Cell parameters
a = 9.398(1) Å · b = 9.139(2) Å · c = 10.535(2) Å
Ratio a:b:c
1 : 0.972 : 1.121
Z
8
Morphology

Prismatic, sheaves

Type-locality form

Colorless to milky white wheat-sheaf polycrystals and euhedral crystals.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
20CaCalciumCalcium240.07880.156
32.69%
8OOxygenOxygen515.99979.995
32.63%
25MnManganeseManganese154.93854.938
22.41%
14SiSiliconSilicon128.08528.085
11.45%
1HHydrogenHydrogen21.0082.016
0.82%
Total245.190100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Fe
  • Mg
  • H2O

Synonyms

  • IMA1992-012
  • Poldervaartiet

In other languages

German
IMA 1992-012 · Poldervaartit
Italian
Poldervaartite

Classification

Strunz
10th ed.

9.AF.90

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AFNesosilicates with additional anions; cations in [4], [5] and/or only [6] coordinationGroup
  • 9.AF.90PoldervaartiteSpecies
Dana
8th ed.

78.01.08.01

  • 78Unclassified SilicatesClass
  • 78.01MiscellaneousType
  • 78.01.08— unnamed intermediate level —Group
  • 78.01.08.01PoldervaartiteSpecies

Literature, links & citation

Citations
  1. 1993Dai, Yongshan, Harlow, George E., Mcghie, Andrew R. (1993) Poldervaartite, Ca(Ca0.5Mn0.5)(SiO3OH)(OH), a new acid nesosilicate from the Kalahari manganese field, South Africa: Crystal structure and description. American Mineralogist, 78 (9-10) 1082-1087
  2. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  3. 2001(2001) Poldervaartite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2007Bonazzi, P., Bindi, L., Medenbach, O., Pagano, R., Lampronti, G. I., Menchetti, S. (2007) Olmiite, CaMn[SiO3(OH)](OH), the Mn-dominant analogue of poldervaartite, a new mineral species from Kalahari manganese fields (Republic of South Africa). Mineralogical Magazine, 71 (2). 193-201 doi:10.1180/minmag.2007.071.2.193 DOI: 10.1180/minmag.2007.071.2.193
  5. 2015Frost, Ray L., López, Andrés, Scholz, Ricardo, Lima, Rosa Malena Fernandes (2015) Vibrational spectroscopic study of poldervaartite CaCa[SiO3(OH)(OH)]. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 137. 827-831 doi:10.1016/j.saa.2014.09.017DOI: 10.1016/j.saa.2014.09.017
