Probertite

NaCaB5O7(OH)4 · 3H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Pbr
Discovered
1929
Also known as
  • Boydite
  • Kramerit
  • Kramerita
  • +2 more

Where it forms, where it's found

Geological setting

Lake-bed deposits.

Type locality
Baker Mine
  1. Rio Tinto Borax Mine
  2. Kramer Borate deposit
  3. Boron
  4. Kern County
  5. California
  6. USA
27recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · white · colourless in transmitted light
Streak
White
Tenacity
brittle
Cleavage
Perfect

On (110).

Density
2.135 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 73° · 2V calc = 74°
Refractive index
1.514 – 1.544
Surface relief
Moderate
Principal indices
nα 1.514 – 1.517 · nβ 1.524 – 1.525 · nγ 1.543 – 1.544
Dispersion
Relatively weak.
Extinction
Y = b; Z ∧ c = 12°–13°.
Michel-Lévy diagramhighlighted lineδ = 0.0280
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]280 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation280 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 13.428(2) Å · b = 12.560(2) Å · c = 6.588(1) Å
Cell angles
β = 99.97(1) °
Ratio a:b:c
1 : 0.935 : 0.491
Z
4
Morphology

Crystals aggregated into rosettes or radial groups of needles or laths. Spherulitic; as tough, compactly reticulated aggregates. Single crystals rare. Crystals acicular [001], commonly flattened (100) (slightly to considerably); also flattened (110), rare. Faces "b," "a," and "m" usually striated [001] and rounded.

Twinning

Doubtful under the microscope.

Type-locality form

Acicular to elongated.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
63.78%
5BBoronBoron510.81054.050
15.39%
20CaCalciumCalcium140.07840.078
11.41%
11NaSodiumSodium122.99022.990
6.55%
1HHydrogenHydrogen101.00810.080
2.87%
Total351.184100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Boydite
  • Kramerit
  • Kramerita
  • Kramerite
  • Probertiet

In other languages

French
Probertite
German
Probertit
Italian
Probertite

Classification

Strunz
10th ed.

6.EB.15

  • 6BoratesClass
  • 6.EPentaboratesDivision
  • 6.EBIno-pentaboratesGroup
  • 6.EB.15ProbertiteSpecies
Dana
8th ed.

26.05.12.01

  • 26Hydrated Borates Containing Hydroxyl or HalogenClass
  • 26.05PentaboratesType
  • 26.05.12— unnamed intermediate level —Group
  • 26.05.12.01ProbertiteSpecies
CIM

9.3.20

  • 9BoratesClass
  • 9.3Borates of Ca and SrGroup
  • 9.3.20ProbertiteSpecies

Literature, links & citation

Citations
  1. 1929Eakle, Arthur S. (1929) Probertite, a new borate. American Mineralogist, 14 (11) 427-430
  2. 1930Foshag, W.F. (1930) New mineral names. American Mineralogist, 15 (7). 274-276
  3. 1930Schaller, W.T. (1930) Borate minerals from the Kramer District Mohave Desert, California. USGS Professional Paper 158: 137. (as Kramerite).
  4. 1931Foshag, William Frederick (1931) Probertite from Ryan, Inyo County, California. American Mineralogist, 16 (8) 338-341
  5. 1949Barnes, William (1949) The unit cell and space group of probertite. American Mineralogist, 34 (1-2) 19-25
