Rabejacite

Ca2[(UO2)4O4(SO4)2](H2O)8
IMA status
  • Approved
IMA symbol
Rbj
Discovered
1993
Also known as
  • IMA1992-043
  • Rabejaciet

Where it forms, where it's found

Geological setting

Secondary mineral. Oxidation zone of uranium deposit.

Oxidation zone of deposits containing uraninite.

Type locality
Rabejac Est
  1. Le Puech
  2. Lodève
  3. Hérault
  4. Occitanie
  5. France

43.6847°, 3.3429°

16recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Bright to amber yellow
Cleavage
None Observed
Density
4.325 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 68° · 2V calc = 68°
Refractive index
1.617 – 1.758
Surface relief
High
Principal indices
nα 1.617 · nβ 1.71 · nγ 1.758
Pleochroism
Strong

Y= very pale yellow Z= sulfur yellow

Dispersion
r > v weak
Extinction
X = c; Y and Z ⊥ [001].
UV response
Pale yellow under SW and LW UV.
Michel-Lévy diagramhighlighted lineδ = 0.1410
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1410 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1410 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 8.7434(11) Å · b = 8.309(3) Å · c = 8.8693(10) Å
Cell angles
α = 77.86(2) ° · β = 104.635(11) ° · γ = 82.935(18) °
Ratio a:b:c
1 : 0.950 : 1.014
Z
1
Morphology

Flattened crysyals or acicular. Rosettes, rounded nodules, crusts.

Type-locality form

Acicular crystals, flattened tablets on (001) to 0.1 mm, or rounded nodules to 0.3 mm

Comment

Originally given cell is orthorhombic, with a = 8.73, b = 17.09, c = 15.72 Å (Z = 4).

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium4238.029952.116
61.01%
8OOxygenOxygen2815.999447.972
28.71%
20CaCalciumCalcium240.07880.156
5.14%
16SSulfurSulfur232.06064.120
4.11%
1HHydrogenHydrogen161.00816.128
1.03%
Total1560.492100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1992-043
  • Rabejaciet

In other languages

German
IMA 1992-043 · Rabejacit
Italian
rabejacite

Classification

Strunz
10th ed.

7.EC.10

  • 7SulfatesClass
  • 7.EUranyl sulfatesDivision
  • 7.ECWith medium-sized and large cationsGroup
  • 7.EC.10RabejaciteSpecies
Dana
8th ed.

31.06.08.01

  • 31Hydrated Sulfates Containing Hydroxyl or HalogenClass
  • 31.06(AB)5(XO4)2Zq·xH2OType
  • 31.06.08— unnamed intermediate level —Group
  • 31.06.08.01RabejaciteSpecies

Literature, links & citation

Citations
  1. 1993Deliens, Michel, Piret, Paul (1993) La rabejacite, Ca(UO2)4(SO4)2(OH)6·6H2O, nouveau sulfate d'uranyle et de calcium des gites du Lodévois, Hérault, France. European Journal of Mineralogy, 5 (5) 873-877 doi:10.1127/ejm/5/5/0873 DOI: 10.1127/ejm/5/5/0873
  2. 1994Jambor, John L., Roberts, Andrew C., Puziewicz, Jacek (1994) New Mineral Names. American Mineralogist, 79 (5-6) 570-574
  3. 1997Mandarino, Joseph A. (1997) New Minerals 1990-1994. The Mineralogical Record Inc., Tuscon, Arizona. 220pp.
  4. 2000Sejkora, J., Čejka, J., Ondruš, P. (2000) New data of rabejacite (Jáchymov, the Krusné Hory Mts., Czech Republic) Neues Jahrbuch für Mineralogie - Monatshefte, 2000 (7) 289-301
  5. 2004Frost, Ray L., Henry, Dermot A., Erickson, Kristy (2004) Raman spectroscopic detection of wyartite in the presence of rabejacite. Journal of Raman Spectroscopy, 35 (4). 255-260 doi:10.1002/jrs.1144DOI: 10.1002/jrs.1144
