Rajite

CuTe4+2O5
IMA status
  • Approved
IMA symbol
Raj
Discovered
1978
IMA approved
1978
Also known as
  • IMA1978-039
  • Rajiet

Where it forms, where it's found

Geological setting

Silicified rhyolite breccia

Type locality
Lone Pine Mine
  1. Lone Pine Hill area
  2. Wilcox Mining District
  3. Catron County
  4. New Mexico
  5. USA

33.2373°, -108.7198°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Bright Duesbury green
Streak
Pale green
Tenacity
brittle
Cleavage
Imperfect/Fair

On (010)

Density
5.75 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 40° · 2V calc = 46°
Refractive index
2.115 – 2.26
Surface relief
Very high
Principal indices
nα 2.115 · nβ 2.135 · nγ 2.26
Pleochroism
Weak

Watery greens

Dispersion
strong
UV response
No fluorescence under LW or SW UV
Michel-Lévy diagramhighlighted lineδ = 0.1450
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1450 nm3rd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1450 nm
Order3rd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#14
Cell parameters
a = 6.866 Å · b = 9.314 Å · c = 7.598 Å
Cell angles
β = 109.1 °
Ratio a:b:c
1 : 1.357 : 1.107
Z
4
Morphology

As tabular to bladed crystals.

Type-locality form

Sprays of bladed to tabular crystals to 1.5 mm. Some bundles of more prismatic crystals comprise are pseudomorphs, possibly after teinite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
52TeTelluriumTellurium2127.600255.200
64.00%
8OOxygenOxygen515.99979.995
20.06%
29CuCopperCopper163.54663.546
15.94%
Total398.741100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1978-039
  • Rajiet

In other languages

German
IMA 1978-039 · Rajit
Italian
Rajite

Classification

Strunz
10th ed.

4.JK.20

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JKTellurites without additional anions, without H2OGroup
  • 4.JK.20RajiteSpecies
Dana
8th ed.

34.04.02.01

  • 34Selenites, Tellurites and SulfitesClass
  • 34.04A(X2O5)Type
  • 34.04.02— unnamed intermediate level —Group
  • 34.04.02.01RajiteSpecies
CIM

28.3.2

  • 28Selenites, Selenates, Tellurites, and TelluratesClass
  • 28.3TelluritesGroup
  • 28.3.2RajiteSpecies

Literature, links & citation

Citations
  1. 1978Hanke, K., Kupčik, V., Lindqvist, O. (1978) The crystal structure of CuTe2O5. Acta Crystallographica: B29: 963-970.
  2. 1979Fleischer, Michael, Burns, Roger G., Cabri, Louis J., Chao, George Y., Hogarth, D. D., Pabst, Adolf (1979) New Mineral Names. American Mineralogist, 64 (11-12) 1329-1334
  3. 1979Williams, S.A. (1979) Rajite, naturally occurring cupric pyrotellurite, a new mineral. Mineralogical Magazine: 43: 91-92.
  4. 2005(2005) Rajite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2008Frost, Ray L., Dickfos, Marilla J., Keeffe, Eloise C. (2008) Raman spectroscopic study of the tellurite minerals: Rajite and denningite. Spectrochimica Acta Part A: Molecular and Biomolecular Spectroscopy, 71 (4) 1512-1515 doi:10.1016/j.saa.2008.05.012DOI: 10.1016/j.saa.2008.05.012
