Rankamaite

(Na,K)3(Ta,Nb,Al)11(O,OH)31
IMA status
  • Approved
IMA symbol
Rkm
Discovered
1969
Also known as
  • IMA1968-002
  • Rankamaiet

Where it forms, where it's found

Geological setting

Alluvial, probably from a lithium pegmatite. Thought to be an alteration of simpsonite.

Type locality
Mumba cassiterite gravels
  1. Mumba
  2. Osso
  3. Masisi Territory
  4. North Kivu
  5. DR Congo

-1.4560°, 28.8844°

5recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Creamy-white

In thin sections, appears bluish-grey to brownish.

Density
5.5 g/cm³

Optical

Optical type
Biaxial
Refractive index
2.1
Surface relief
Very high
Principal indices
nβ 2.1
Dispersion
r < v extreme
Extinction
Z = c and, X ⊥ c
Notes

Elongation positive. Refractive indices > 2.10.

Crystallography

Crystal system
Orthorhombic
Space group
Cmmm
Cell parameters
a = 17.224(3) Å · b = 17.687(3) Å · c = 3.9361(7) Å
Cell angles
α = 90 ° · β = 90 ° · γ = 90 °
Ratio a:b:c
1 : 1.027 : 0.229
Unit cell volume
1199.1 ų
Z
2
Type-locality form

Water-worn pebbles found in heavy mineral concentrates. Silky, fibrous (asbestiform). The fibers are generally wavy but tufts of straight fibres can be seen in small cavities.

Comment

Atencio et al. (2011)

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
73TaTantalumTantalum11180.9481990.428
44.05%
41NbNiobiumNiobium1192.9061021.966
22.62%
8OOxygenOxygen6215.999991.938
21.95%
13AlAluminiumAluminium1126.982296.802
6.57%
19KPotassiumPotassium339.098117.294
2.59%
11NaSodiumSodium322.99068.970
1.53%
1HHydrogenHydrogen311.00831.248
0.69%
Total4518.646100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1968-002
  • Rankamaiet

In other languages

German
Rankamait
Spanish
Rankamaíta
Italian
Rankamaite

Classification

Strunz
10th ed.

4.DM.05

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DMWith large (+- medium-sized) cations; unclassifiedGroup
  • 4.DM.05RankamaiteSpecies
Dana
8th ed.

08.07.06.01

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.07MiscellaneousType
  • 08.07.06— unnamed intermediate level —Group
  • 08.07.06.01RankamaiteSpecies
CIM

18.1.7

  • 18Niobates and TantalatesClass
  • 18.1Niobates and tantalates containing neither rare earths nor UGroup
  • 18.1.7RankamaiteSpecies

Literature, links & citation

Citations
  1. 1969von Knorring, O., Vorma, A., Nixon, P.H. (1969) Rankamaite, a new tantalum mineral from Kivu, Congo. Bulletin of the Geological Society of Finland, 41. 47-56 doi:10.17741/bgsf/41.003DOI: 10.17741/bgsf/41.003
  2. 1970Fleischer, M., Nickel, E.H. (1970) New mineral names. American Mineralogist: 55: 1810-1818.
  3. 1984Nekrasov, I.Y., Chistyakova, N.I., Yevstigneyeva, T.L. (1984) On the relationships of thoreaulite, lithiotantite, rankamaite and cassiterite in rare-element pegmatites of Siberia. Mineralogicheskyi Zhurnal: 6: 42-55.
  4. 2005(2005) Rankamaite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2011Atencio, D., Filho, R. R. C., Mills, S. J., Coutinho, J. M. V., Honorato, S. B., Ayala, A. P., Ellena, J., de Andrade, M. B. (2011) Rankamaite from the Urubu pegmatite, Itinga, Minas Gerais, Brazil: Crystal chemistry and Rietveld refinement. American Mineralogist, 96 (10) 1455-1460 doi:10.2138/am.2011.3594 DOI: 10.2138/am.2011.3594
