Reinerite

Zn3(AsO3)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Rnr
Discovered
1958
Also known as
  • Reineriet

Where it forms, where it's found

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

4recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105 – 5.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Colour
Originally blue toyellow green · also colorless to white

Light yellow-green, changing to sea-blue on exposure.

Cleavage
Distinct/Good

(110), (011), (111), good

Density
4.270 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.749 – 1.821
Surface relief
High
Principal indices
nα 1.749 · nβ 1.790 · nγ 1.821
Dispersion
r > v moderate
UV response
Fluoresces medium olive-green
Michel-Lévy diagramhighlighted lineδ = 0.0720
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]720 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation720 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pbam
Cell parameters
a = 6.0883(2) Å · b = 14.3941(5) Å · c = 7.8022(2) Å
Ratio a:b:c
1 : 2.364 : 1.282
Z
4
Type-locality form

Crystals are rough, pseudohexagonal.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
30ZnZincZinc365.380196.140
44.38%
33AsArsenicArsenic274.922149.844
33.90%
8OOxygenOxygen615.99995.994
21.72%
Total441.978100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Reineriet

In other languages

German
Reinerit
Spanish
Reinerita
Italian
Reinerite

Classification

Strunz
10th ed.

4.JA.10

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JAArsenites, antimonites, bismuthites; without additional anions, without H2OGroup
  • 4.JA.10ReineriteSpecies
Dana
8th ed.

45.01.01.01

  • 45Acid and Normal Antimonites and ArsenitesClass
  • 45.01MiscellaneousType
  • 45.01.01— unnamed intermediate level —Group
  • 45.01.01.01ReineriteSpecies

Literature, links & citation

Citations
  1. 1958Geier, Bruno H., Weber, Kurt (1958) Reinerit, Zn3(AsO3)2, ein neues Mineral der Tsumeb Mine, Sudwestafrika. Neues Jahrbuch für Mineralogie - Monatshefte, 1958. 160-167
  2. 1959Fleischer, Michael (1959) New Mineral Names. American Mineralogist, 44 (1-2). 207-210
  3. 1977Ghose, Subrata, Boving, Paul, LaChapelle, William A., Wan, Che'ng (1977) Reinerite, Zn3(AsO3)2: an arsenite with a novel type of Zn-tetrahedral double chain. American Mineralogist, 62 (11-12) 1129-1134
  4. 1983Neues Jahrbuch für Mineralogie, Monatshefte (1983): 119.
  5. 1994Breidenstein, B. (1994) Powder diffraction data of natural reinerite Zn3(AsO3)2. Neues Jahrbuch für Mineralogie Monatshefte, 1994(4), 174-178.
