Retzian-(Ce)

Mn2+2Ce(AsO4)(OH)4
IMA status
  • Approved
IMA symbol
Rtz-Ce
Also known as
  • Retzian

Where it forms, where it's found

Geological setting

Cavities in dolomite.

Type locality
Moss mine
  1. Nordmark Odal Field
  2. Filipstad
  3. Värmland County
  4. Sweden

59.8167°, 14.1000°

6recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Chocolate brown to chestnut-brown · brown in transmitted light.
Streak
Light brown
Fracture
Irregular/Uneven · Conchoidal
Density
4.15 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
1.777 – 1.8
Surface relief
High
Principal indices
nα 1.777 · nβ 1.788 · nγ 1.8
Pleochroism
Strong

X = Nearly colourless to orange-yellow; Y = Yellowish brown to dark brown; Z = Red-brown to crimson red.

Dispersion
r > v slight
Extinction
Parallel. X = c; Y = b; Z = a.
Michel-Lévy diagramhighlighted lineδ = 0.0230
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]230 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation230 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Pban
Cell parameters
a = 5.670(3) Å · b = 12.03(1) Å · c = 4.863(4) Å
Ratio a:b:c
1 : 2.122 : 0.858
Z
2
Morphology

Crystals prismatic [001], sometimes also tabular (010). Forms include (010), (001), (110), (130), (101).

Twinning

On (150), doubtful.

Type-locality form

Crystals 2-3 mm in length, prismatic or thickly tabular.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
58CeCeriumCerium1140.116140.116
30.66%
8OOxygenOxygen815.999127.992
28.01%
25MnManganeseManganese254.938109.876
24.05%
33AsArsenicArsenic174.92274.922
16.40%
1HHydrogenHydrogen41.0084.032
0.88%
Total456.938100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Retzian

In other languages

German
Retzian-(Ce)
Italian
Retzian- · Retzian-(Ce)

Classification

Strunz
10th ed.

8.BM.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.BPhosphates, etc., with additional anions, without H2ODivision
  • 8.BMWith medium-sized and large cations, (OH, etc.):RO4 = 4:1Group
  • 8.BM.05Retzian-(Ce)Species
Dana
8th ed.

41.03.04.01

  • 41Anhydrous Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 41.03(AB)3(XO4)ZqType
  • 41.03.04Retzian SeriesGroup
  • 41.03.04.01Retzian-(Ce)Species
CIM

20.4.16

  • 20Arsenates (also arsenates with phosphate, but without other anions)Class
  • 20.4Arsenates of Group III metals (Al, rare earths)Group
  • 20.4.16Retzian-(Ce)Species

Group, growth & confusion

In the same group
2 members
Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1894Sjogren, H. (1894) Retzian, a new arseniate from the Mossgrufva, Nordmark. Bulletin of the Geological Institution of the University of Upsala, 2, 54-59. (as retzian).
  2. 1897Sjögren (1897) Geologiska Föeningens I Stockholm. Förhandlinger, Stockholm: 19.
  3. 1921Larsen, Esper S. (1921) The microscopic determination of the nonopaque minerals. Bulletin 679. US Geological Survey doi:10.3133/b679 DOI: 10.3133/b679
  4. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
  5. 1967Moore, Paul B. (1967) Crystal chemistry of the basic manganese arsenate minerals: I. The crystal structures of flinkite, Mn2+2Mn3+(OH)4(AsO4) and retzian, Mn2+2Y3+(OH)4(AsO4) American Mineralogist, 52 (11-12) 1603-1613
