Reynoldsite

Pb2Mn4+2O5(CrO4)
IMA status
  • Approved
IMA symbol
Ryn
IMA approved
2011
Also known as
  • IMA2011-051
  • Reynoldsiet
  • UM2006-04-O:CrHMnPb

Where it forms, where it's found

Geological setting

Oxidation zone.

Type locality
Red Lead Mine
  1. Dundas mineral field
  2. Zeehan mining district
  3. West Coast municipality
  4. Tasmania
  5. Australia

-41.8894°, 145.4308°

3recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark orange-brown to black

The orange-brown color is only seen in very thin crystals in strong transmitted light.

Streak
Dark orange-brown
Tenacity
brittle
Cleavage
Poor/Indistinct

Parallel to (001)

Fracture
Irregular/Uneven · Splintery
Density
6.574 g/cm³

Optical

Optical type
Biaxial
Pleochroism
Visible

Medium brown along [100] to dark orange-brown along [010]*

Extinction
Extinction is approximately parallel to [100], the direction of prism elongation for Blue Bell crystals and of the plate edges of Red Lead crystals.
UV response
Not fluorescent.
Notes

The Gladstone-Dale relationship predicts n_average = 2.473 for the ideal formula.

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 5.0278(7) Å · b = 7.5865(11) Å · c = 10.2808(15) Å
Cell angles
α = 91.968(10) ° · β = 99.405(12) ° · γ = 109.159(10) °
Ratio a:b:c
1 : 1.509 : 2.045
Z
2
Morphology

Thin prisms, elongated parallel to [100] with a square cross section and a chisel-like termination.

Twinning

Multiple penetration and reticulated twinning by rotations on [100] and [120] and about the normal to (001).

Type-locality form

Subparallel growths and divergent sprays of thin prisms with a square cross section and a chisel-like termination. Also as thin rectangular blades.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead2207.200414.400
57.53%
8OOxygenOxygen915.999143.991
19.99%
25MnManganeseManganese254.938109.876
15.26%
24CrChromiumChromium151.99651.996
7.22%
Total720.263100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2011-051
  • Reynoldsiet
  • UM2006-04-O:CrHMnPb

In other languages

German
IMA 2011-051 · Reynoldsit
Italian
reynoldsite

Classification

Strunz
10th ed.

7.FB.30

  • 7SulfatesClass
  • 7.FChromatesDivision
  • 7.FBWith additional O,V, S, ClGroup
  • 7.FB.30ReynoldsiteSpecies

Literature, links & citation

Citations
  1. 2011Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2011) New minerals and nomenclature modifications approved in 2011, CNMNC Newsletter No. 10. Mineralogical Magazine, 75 (5) 2549-2561 doi:10.1180/minmag.2011.075.5.2549 DOI: 10.1180/minmag.2011.075.5.2549
  2. 2012Kampf, A. R., Mills, S. J., Housley, R. M., Bottrill, R. S., Kolitsch, U. (2012) Reynoldsite, Pb2Mn4+2O5(CrO4), a new phyllomanganate-chromate from the Blue Bell claims, California and the Red Lead mine, Tasmania. American Mineralogist, 97 (7) 1187-1192 doi:10.2138/am.2012.3989 DOI: 10.2138/am.2012.3989
  3. 2017(2017) Reynoldsite. Handbook of Mineralogy. Mineralogical Society of America
