Rodalquilarite

H3Fe3+2(Te4+O3)4Cl
IMA status
  • Approved
IMA symbol
Raq
Discovered
1967
IMA approved
1967
Also known as
  • IMA1967-040
  • Rodalquilariet

Where it forms, where it's found

Geological setting

Oxidation zone of a gold deposit

Oxidation zone of tellurium-bearing precious metal deposits.

Type locality
Filón 340
  1. Rodalquilar
  2. Níjar
  3. Almería
  4. Andalusia
  5. Spain

36.8491°, -2.0601°

11recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102 – 3/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Emerald- to grass-green
Streak
Greenish yellow
Tenacity
very brittle
Cleavage
Distinct/Good

One good cleavage

Density
4.97 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 38°
Refractive index
2.1 – 2.2
Surface relief
Very high
Principal indices
nα 2.1 · nγ 2.2
Pleochroism
Non-pleochroic
Dispersion
r < v extreme
Michel-Lévy diagramhighlighted lineδ = 0.1000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]1000 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation1000 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 8.95(5) Å · b = 5.09(1) Å · c = 6.63 Å
Cell angles
α = 103.17 ° · β = 107.08 ° · γ = 77.87 °
Ratio a:b:c
1 : 0.569 : 0.741
Z
1
Morphology

Stout crystals to 2.5cm, crusts.

Type-locality form

Tiny stout crystals, mostly less than 0.1 mm and in crusts in quartz geodes.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
52TeTelluriumTellurium4127.600510.400
59.87%
8OOxygenOxygen1215.999191.988
22.52%
26FeIronIron255.845111.690
13.10%
17ClChlorineChlorine135.45035.450
4.16%
1HHydrogenHydrogen31.0083.024
0.35%
Total852.552100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1967-040
  • Rodalquilariet

In other languages

French
Rodalquilarite
German
IMA1967-040 · Rodalquilarit
Spanish
Rodalquilarita
Italian
Rodalquilarite

Classification

Strunz
10th ed.

4.JL.05

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JLTellurites with additional anions, without H2OGroup
  • 4.JL.05RodalquilariteSpecies
Dana
8th ed.

34.06.02.01

  • 34Selenites, Tellurites and SulfitesClass
  • 34.06Anhydrous Selenites, Tellurites and Sulfites containing Hydroxyl or HalogenType
  • 34.06.02— unnamed intermediate level —Group
  • 34.06.02.01RodalquilariteSpecies
CIM

28.3.26

  • 28Selenites, Selenates, Tellurites, and TelluratesClass
  • 28.3TelluritesGroup
  • 28.3.26RodalquilariteSpecies

Literature, links & citation

Citations
  1. 1968Sierra Lopez, J., Leal, G., Pierrot, Roland, Laurent, Yvette, Protas, Jean, Dusausoy, Yves (1968) La rodalquilarite, chlorotellurite de fer, une nouvelle espèce minérale. Bulletin de Minéralogie, 91 (1) 28-33 doi:10.3406/bulmi.1968.6183 DOI: 10.3406/bulmi.1968.6183
  2. 1968Fleisher, Michael (1968) New Mineral Names. American Mineralogist, 53 (11-12) 2103-2106
  3. 1969Dusausoy, Y., Protas, J. (1969) Détermination et étude de la structure cristalline de la rodalquilarite, chlorotellurite acide de fer. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 25 (8) 1551-1558 doi:10.1107/s0567740869004316DOI: 10.1107/s0567740869004316
  4. 1999Feger, C.R., Kolis, J.W., Gorny, K., Pennington, C. (1999) Rodalquilarite revisited: the hydrothermal synthesis and structural reinvestigation of H3Fe2(TeO3)4Cl. Journal of Solid State Chemistry: 143: 254-259.
  5. 2005(2005) Rodalquilarite. Handbook of Mineralogy. Mineralogical Society of America
