Ronneburgite

K2MnV4O12
IMA status
  • Approved
IMA symbol
Rbu
Discovered
1998
IMA approved
1998
Also known as
  • IMA1998-069
  • Ronneburgiet

Where it forms, where it's found

Type locality
Lichtenberg Absetzer dump
  1. Kauern
  2. Greiz District
  3. Thuringia
  4. Germany

50.8394°, 12.1573°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Adamantine
Transparency
Translucent
Colour
Reddish brown
Streak
Orange brown
Tenacity
brittle
Cleavage
Poor/Indistinct

Indistinct in one direction

Fracture
Irregular/Uneven
Density
2.84 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 82°
Refractive index
1.925 – 1.988
Surface relief
Very high
Principal indices
nα 1.925 · nβ 1.960 · nγ 1.988
Pleochroism
Weak

X = brownish orange with distinct reddish tint, Y = brownish orange, Z = brownish orange. Thick crystals pleochroic in dark red-orange.

Dispersion
r > v strong
Michel-Lévy diagramhighlighted lineδ = 0.0630
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]630 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation630 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 8.183(3) Å · b = 9.247(3) Å · c = 8.651(2) Å
Cell angles
β = 109.74(2) °
Ratio a:b:c
1 : 1.130 : 1.057
Unit cell volume
616.1 ų
Z
2
Type-locality form

Equant, flattened, or short prismatic crystals to 0.5 mm.

Comment

Space Group: P21/n.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
23VVanadiumVanadium450.942203.768
38.53%
8OOxygenOxygen1215.999191.988
36.30%
19KPotassiumPotassium239.09878.196
14.78%
25MnManganeseManganese154.93854.938
10.39%
Total528.890100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1998-069
  • Ronneburgiet

In other languages

German
IMA 1998-069 · Ronneburgit
Italian
Ronneburgite

Classification

Strunz
10th ed.

8.AC.75

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ACWith medium-sized and large cationsGroup
  • 8.AC.75RonneburgiteSpecies

Literature, links & citation

Citations
  1. 2001Witzke, Thomas, Zhen, Shenyan, Seff, Karl, Doering, Thomas, Nasdala, Lutz, Kolitsch, Uwe (2001) Ronneburgite, K2MnV4O12, a new mineral from Ronneburg, Thuringia, Germany: Description and crystal structure. American Mineralogist, 86 (9) 1081-1086 doi:10.2138/am-2001-8-915 DOI: 10.2138/am-2001-8-915
  2. 2021(2021) Ronneburgite. Handbook of Mineralogy. Mineralogical Society of America
