Rosenhahnite

Ca3Si3O8(OH)2
IMA status
  • Approved
IMA symbol
Rhh
Discovered
1962
Also known as
  • IMA1965-030
  • Rosenhahniet

Where it forms, where it's found

Geological setting

Veins in brecciated, fine-grained diopside-garnet metasedimentary rock.

Type locality
Rosenhahnite occurrence
  1. Russian River
  2. Cloverdale area
  3. Mendocino County
  4. California
  5. USA

38.8853°, -123.0444°

6recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104.5 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
White · beige · colourless · yellow-brown
Streak
White
Cleavage
Perfect

Perfect on (001), good on (100) and (010).

Density
2.89 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 64° · 2V calc = 64°
Refractive index
1.624 – 1.647
Surface relief
Moderate
Principal indices
nα 1.624 – 1.625 · nβ 1.640 – 1.641 · nγ 1.646 – 1.647
Dispersion
r < v
UV response
Fluoresces light orangish pink under LW UV.
Michel-Lévy diagramhighlighted lineδ = 0.0220
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]220 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation220 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 6.955(2) Å · b = 9.484(2) Å · c = 6.812(2) Å
Cell angles
α = 108.64(2) ° · β = 94.84(2) ° · γ = 95.89(2) °
Ratio a:b:c
1 : 1.364 : 0.979
Z
2
Morphology

The type crystals are tabular to lathlike with (010) by far the most prominent form. Other forms observed include (001), (100), (140), (110), (210), (110), (210), (032), (021), (031), (101), (122).

Type-locality form

Narrow veinlets less than 3 cm thick with small pockets.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1015.999159.990
43.65%
20CaCalciumCalcium340.078120.234
32.81%
14SiSiliconSilicon328.08584.255
22.99%
1HHydrogenHydrogen21.0082.016
0.55%
Total366.495100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • B
  • Al
  • Fe
  • Mn
  • Mg
  • Sr
  • Ba
  • Na
  • H2O

Synonyms

  • IMA1965-030
  • Rosenhahniet

In other languages

German
IMA 1965-030 · Rosenhahnit
Italian
Rosenhahnite

Classification

Strunz
10th ed.

9.BJ.10

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BJSorosilicates with Si3O10, Si4O11, etc. anions; cations in octahedral [6] and greater coordinationGroup
  • 9.BJ.10RosenhahniteSpecies
Dana
8th ed.

57.01.04.01

  • 57Sorosilicates Si3o10 Groups and Larger Noncyclic GroupsClass
  • 57.01Insular Si3O10 and Larger Noncyclic Groups with [Si3O10] groupsType
  • 57.01.04— unnamed intermediate level —Group
  • 57.01.04.01RosenhahniteSpecies
CIM

14.5.9

  • 14Silicates not Containing AluminumClass
  • 14.5Silicates of CaGroup
  • 14.5.9RosenhahniteSpecies

Literature, links & citation

Citations
  1. 1967Pabst, A., Gross, E. B., Alfors, J. T. (1967) Rosenhahnite, a new hydrous calcium silicate, from Mendocino County, California. American Mineralogist, 52 (3-4) 336-351
  2. 1973Jeffery, J.W., Lindley, P.F. (1973) Remarkable new silicate structure. Nature: 241: 42-43.
  3. 1977Wan, Che'ng, Ghose, Subrata, Gibbs, G. V. (1977) Rosenhahnite, Ca3Si3O8(OH)2: crystal structure and the stereochemical configuration of the hydroxylated trisilicate group, [Si3O8(OH)2]. American Mineralogist, 62 (5-6) 503-512
  4. 2000Zadov, A.E., Chukanov, N.V., Organova, N.I., Kuz'mina, O.V., Belakovskii, D.I., Nechai, V.G., Sokolovskii, F.S., Kuznetsova, O.Yu. (2000) Comparative study of rosenhahnite from California and from the Urals. Improvement of the formula. Zapiski Vserossiiskogo Mineralogicheskogo Obshchestva: 129: 85-96. (in Russian)
  5. 2001(2001) Rosenhahnite. Handbook of Mineralogy. Mineralogical Society of America
