Rüdlingerite

Mn2+2V5+As5+O7 · 2H2O
IMA status
  • Approved
IMA symbol
Rdg
IMA approved
2017
Also known as
  • IMA2016-054a
  • Rüdlingeriet

Where it forms, where it's found

Geological setting

Metamorphic manganese deposit: mineralized veins cutting quartz-hematite ore

Type locality
Fianel
  1. Ausserferrera
  2. Ferrera
  3. Viamala Region
  4. Grisons
  5. Switzerland

46.5464°, 9.4622°

2recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
light orange to light yellow orange · yellow
Streak
yellow white
Tenacity
brittle
Cleavage
Perfect

(001)

Curved fracture

Fracture
Sub-Conchoidal
Density
3.28 g/cm³

Optical

Optical type
Biaxial
Pleochroism
Strong

strong pleochroism from yellow to orange; it displays positive elongation; Z ˄ c ~ 14°. For the Valletta specimen, X = yellow, Y = orange yellow, Z = brownish orange; X < Y << Z.

Notes

average refractive index calculated using the Gladstone-Dale relationship is 1.791 < n<f>^a^v</f> < 1.799

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 7.8289(2) Å · b = 14.5673(4) Å · c = 6.7011(2) Å
Cell angles
β = 93.773(2) °
Ratio a:b:c
1 : 1.861 : 0.856
Z
4
Parting
None observed
Type-locality form

Prismatic crystals that reach 300 μm

Comment

Spacegroup: P21/n

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
37.52%
25MnManganeseManganese254.938109.876
28.63%
33AsArsenicArsenic174.92274.922
19.52%
23VVanadiumVanadium150.94250.942
13.28%
1HHydrogenHydrogen41.0084.032
1.05%
Total383.763100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2016-054a
  • Rüdlingeriet

In other languages

German
IMA 2016-054a · Rüdlingerit

Classification

Strunz
10th ed.

8.FC.05

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.FPolyphosphates, Polyarsenates, [4]-PolyvanadatesDivision
  • 8.FCPolyphosphates, etc., with H2O onlyGroup
  • 8.FC.05RüdlingeriteSpecies

Literature, links & citation

Citations
  1. 2017Hålenius, U., Hatert, F., Pasero, M., Mills, S. J. (2017) New minerals and nomenclature modifications approved in 2017, CNMNC Newsletter No 39. Mineralogical Magazine, 81 (5) 1279-1286 doi:10.1180/minmag.2017.081.072DOI: 10.1180/minmag.2017.081.072
  2. 2018Roth P. and Meisser N. (2018): Rüdlingerit, eine neue Mineralart aus Fianel (GR). Schweizer Strahler, 2018(1), 26–29 (in French and German).
  3. 2020Roth, Philippe, Meisser, Nicolas, Nestola, Fabrizio, Škoda, Radek, Cámara, Fernando, Bosi, Ferdinando, Ciriotti, Marco E., Hålenius, Ulf, Schnyder, Cédric, Bracco, Roberto (2020) Rüdlingerite, Mn2+2V5+As5+O7·2H2O, a New Species Isostructural with Fianelite. Minerals, 10 (11). 960 doi:10.3390/min10110960DOI: 10.3390/min10110960
  4. 2022(2022) Rüdlingerite. Handbook of Mineralogy. Mineralogical Society of America
