Ruitenbergite

Ca9B26O34(OH)24Cl4 · 13H2O
IMA status
  • Approved
IMA symbol
Rtb
Discovered
1993
Also known as
  • IMA1992-011
  • Ruitenbergiet

Where it forms, where it's found

Type locality
Potash Corporation of Saskatchewan Mine (PCS Mine
  1. Potash Corporation of America Mine)
  2. Penobsquis
  3. Cardwell Parish
  4. Kings Co.
  5. New Brunswick
  6. Canada

45.7542°, -65.4211°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless to orange · white · pale yellow
Streak
white
Tenacity
brittle
Cleavage
Distinct/Good

(100), good.

Fracture
Conchoidal
Density
2.13 g/cm³

Optical

Optical type
Biaxial (+) · 2V measured = 47° · 2V calc = 42°
Refractive index
1.542 – 1.565
Surface relief
Moderate
Principal indices
nα 1.542 · nβ 1.545 · nγ 1.565
Dispersion
weak
Optical colour
blue gray
Michel-Lévy diagramhighlighted lineδ = 0.0230
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]230 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation230 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21
Cell parameters
a = 19.857(7) Å · b = 9.708(4) Å · c = 17.522(6) Å
Cell angles
β = 115.68 °
Ratio a:b:c
1 : 0.489 : 0.882
Z
2
Type-locality form

Anhedral granular, to 7 mm.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen7115.9991135.929
57.66%
20CaCalciumCalcium940.078360.702
18.31%
5BBoronBoron2610.810281.060
14.27%
17ClChlorineChlorine435.450141.800
7.20%
1HHydrogenHydrogen501.00850.400
2.56%
Total1969.891100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1992-011
  • Ruitenbergiet

In other languages

German
IMA 1992-011 · Ruitenbergit
Italian
Ruitenbergite

Classification

Strunz
10th ed.

6.GD.05

  • 6BoratesClass
  • 6.GHeptaborates and other megaboratesDivision
  • 6.GDMega-tektoboratesGroup
  • 6.GD.05RuitenbergiteSpecies
Dana
8th ed.

26.05.17.02

  • 26Hydrated Borates Containing Hydroxyl or HalogenClass
  • 26.05PentaboratesType
  • 26.05.17Pringleite GroupGroup
  • 26.05.17.02RuitenbergiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1993Roberts, Andrew C., Stirling, J. A. R., Grice, Joel D., Burns, P. C., Curtis, J. D., Jambor, J. L. (1993) Pringleite and ruitenbergite, polymorphs of Ca2B26O34(OH)24Cl4·13H2O, two new mineral species from Sussex, New Brunswick. The Canadian Mineralogist, 31 (4) 795-800
  2. 1994Grice, Joel D., Burns, Peter C., Hawthorne, Franck C. (1994) Determination of the megastructures of the borate polymorphs pringleite and ruitenbergite. The Canadian Mineralogist, 32 (1) 1-14
  3. 1996Grew, Edward S.; Anovitz, Lawrence M. - Eds. (1996) Boron - Mineralogy, Petrology and Geochemistry. Reviews in Mineralogy Vol. 33. Mineralogical Society of America p.862
  4. 2005(2005) Ruitenbergite. Handbook of Mineralogy. Mineralogical Society of America
  5. 2005Grice, J. D., Gault, R. A., Van Velthuizen, J. (2005) Borate minerals of the Penobsquis and Millstream deposits, southern New Brunswick, Canada. The Canadian Mineralogist, 43 (5) 1469-1487 doi:10.2113/gscanmin.43.5.1469 DOI: 10.2113/gscanmin.43.5.1469
