Sørensenite

Na4Be2Sn(Si3O9)2 · 2H2O
IMA status
  • Approved
IMA symbol
Sør
Discovered
1962
IMA approved
1965
Also known as
  • IMA1965-006
  • Sorensenite
  • Sørenseniet

Where it forms, where it's found

Geological setting

Miarolitic cavities in hydrothermal vents cutting coarse-grained nepheline syenites.

Type locality
Mount Nakkaalaaq
  1. Ilímaussaq complex
  2. Kujalleq
  3. Greenland

60.9667°, -45.9000°

6recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless to pink · milky white (altered) · colourless in transmitted light
Streak
White
Tenacity
brittle
Cleavage
Distinct/Good

On (101) and (100). The angle (10_1) ∧ (100) = 63°.

Density
2.9 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.576 – 1.586
Surface relief
Moderate
Principal indices
nα 1.576 – 1.579 · nβ 1.581 – 1.585 · nγ 1.584 – 1.586
Dispersion
Very weak. The type desciption describes 'strong inclined dispersion'.
Notes

Anomalous interference colors in shades of blue and yellowish brown.

Michel-Lévy diagramhighlighted lineδ = 0.0075
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]75 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation75 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
#10
Cell parameters
a = 20.698 Å · b = 7.442 Å · c = 12.037 Å
Cell angles
β = 117.28 °
Ratio a:b:c
1 : 0.360 : 0.582
Z
4
Morphology

Crystals lath-shaped to acicular parallel to [010]. Forms fan-like and bowtie aggregates by branching from the base of the crystals. Single crystals have a rhombic cross section.

Twinning

Complex and uncommon. Twin axis is perpendicular to [011] in (100).

Type-locality form

Well developed crystals (0.05 mm to 10 cm in size). Elongated tabular or acicular crystals (up to 10 x 1 x 1 cm in size). Single crystals are straight or bent; groups of needles can cross each other in an irregular way. Sheaf-like or radiating growth is rare.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen2015.999319.980
44.37%
14SiSiliconSilicon628.085168.510
23.36%
50SnTinTin1118.710118.710
16.46%
11NaSodiumSodium422.99091.960
12.75%
4BeBerylliumBeryllium29.01218.024
2.50%
1HHydrogenHydrogen41.0084.032
0.56%
Total721.216100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1965-006
  • Sørenseniet
  • Sorensenite

In other languages

German
IMA 1965-006 · Sørensenit
Italian
Sorensenite · Sørensenite

Classification

Strunz
10th ed.

9.DG.30

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DGInosilicates with 3-periodic single and multiple chainsGroup
  • 9.DG.30SørenseniteSpecies
Dana
8th ed.

65.02.04.01

  • 65Inosilicates Single-width, Unbranched Chains, (w=1)Class
  • 65.02Single-Width Unbranched Chains, W=1 with chains P=3Type
  • 65.02.04— unnamed intermediate level —Group
  • 65.02.04.01SørenseniteSpecies
CIM

14.3.16

  • 14Silicates not Containing AluminumClass
  • 14.3Silicates of BeGroup
  • 14.3.16SørenseniteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1965Semenov, E.I., Gerassimovsky, V.I., Maksimova, N.V., Andersen, S., Petersen, O.V. (1965) Sorensenite, a new Sodium-Beryllium-in-Silicate from the Ilîmaussaq Intrusion, South Greenland. Meddelelser om Grønland, 181 (1). 1-19
  2. 1966Fleischer, M. (1966) New Mineral Names. American Mineralogist, 51 (9-10) 1546-1554
  3. 1967Fleischer, M. (1967) New mineral names. American Mineralogist, 52 (5-6). 925-929
  4. 1974Maksimova, N.V., Ilyukhin, V.V., Belov, N.V. (1974) Crystal structure of sorensenite. Soviet Physics - Doklady, 18, 681-682.
  5. 1976Metcalf-Johansen, J., Hazell, R. G. (1976) The crystal structure of sorensenite, Na4SnBe2(Si3O9)2.2H2O. Acta Crystallographica Section B Structural Crystallography and Crystal Chemistry, 32 (9) 2553-2556 doi:10.1107/s0567740876008236DOI: 10.1107/s0567740876008236
