Sabieite

(NH4)Fe3+(SO4)2
IMA status
  • Approved
IMA symbol
Sbi
Discovered
1983
Also known as
  • IMA1982-088
  • Sabieiet

Where it forms, where it's found

Geological setting

Formed by the oxidation of pyrite, which interacts with ammonia produced from the decay of organic matter. Likely to form if the pH is below one.

Dehydration product of lonecreekite.

Type locality
Lone Creek Falls cave
  1. Lone Creek Falls
  2. Sabie
  3. Thaba Chweu Local Municipality
  4. Ehlanzeni District Municipality
  5. Mpumalanga
  6. South Africa

-25.1022°, 30.7092°

12recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
White
Streak
White
Density
2.36 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.578 – 1.595
Surface relief
Moderate
Principal indices
nω 1.578 · nε 1.595
Michel-Lévy diagramhighlighted lineδ = 0.0170
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]170 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation170 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#90
Cell parameters
a = 4.822 Å · c = 8.1696 Å
Z
1
Morphology

Thin platelets.

Comment

By analogy to synthetic material.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen815.999127.992
48.12%
16SSulfurSulfur232.06064.120
24.10%
26FeIronIron155.84555.845
20.99%
7NNitrogenNitrogen114.00714.007
5.27%
1HHydrogenHydrogen41.0084.032
1.52%
Total265.996100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-088
  • Sabieiet

In other languages

French
sabieite
German
IMA 1982-088 · Sabieit
Italian
Sabieite

Classification

Strunz
10th ed.

7.AC.20

  • 7SulfatesClass
  • 7.ASulfates (selenates, etc.) without additional anions, without H2ODivision
  • 7.ACWith medium-sized and large cationsGroup
  • 7.AC.20SabieiteSpecies
Dana
8th ed.

28.03.05.01

  • 28Anhydrous Acid and Normal SulfatesClass
  • 28.03AXO4Type
  • 28.03.05— unnamed intermediate level —Group
  • 28.03.05.01SabieiteSpecies
CIM

25.11.13

  • 25SulphatesClass
  • 25.11Sulphates of Fe and other metalsGroup
  • 25.11.13SabieiteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1984Martini, J.E.J. (1984) Lonecreekite, sabieite, and clairite, new secondary ammonium ferric-iron sulfates from Lone Creek Fall cave, near Sabie, eastern Transvaal. Annals of the Geological Survey (South Africa): 17: 29-34.
  2. 1986Dunn, Pete J., Chao, George Y., Fitzpatrick, Joan J., Langley, Richard H., Fleischer, Michael, Zilczer, Janet A. (1986) New Mineral Names. American Mineralogist, 71 (1-2). 227-232
  3. 2005(2005) Sabieite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2014Kampf, A. R., Richards, R. P., Nash, B. P. (2014) The 2H and 3R polytypes of sabieite, NH4Fe3+(SO4)2, from a natural fire in an oil-bearing shale near Milan, Ohio. American Mineralogist, 99 (7) 1500-1506 doi:10.2138/am.2014.4884DOI: 10.2138/am.2014.4884
  5. 2018Košek, F., Culka, A., Jehlička, J. (2018) Raman spectroscopic study of six synthetic anhydrous sulfates relevant to the mineralogy of fumaroles. Journal of Raman Spectroscopy, 49 (7). 1205-1216 doi:10.1002/jrs.5363DOI: 10.1002/jrs.5363
