Sanbornite

BaSi2O5
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sabn
Discovered
1932

Where it forms, where it's found

Geological setting

Metamorphosed sediments.

Type locality
Trumbull Peak Ba-silicate deposit
  1. Trumbull Peak
  2. Clearing House
  3. Clearing House Mining District
  4. East Belt
  5. Mariposa County
  6. California
  7. USA

37.6919°, -119.8642°

28recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Colourless to white
Streak
White
Tenacity
brittle
Cleavage
Perfect

(001) perfect, imperfect on (100) and (010)

Density
3.70 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 67° · 2V calc = 65°
Refractive index
1.597 – 1.625
Surface relief
Moderate
Principal indices
nα 1.597 · nβ 1.617 · nγ 1.625
Dispersion
r < v weak
Michel-Lévy diagramhighlighted lineδ = 0.0280
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]280 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation280 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Cell parameters
a = 4.629(1) Å · b = 7.688(1) Å · c = 13.523(1) Å
Ratio a:b:c
1 : 1.661 : 2.921
Z
4
Twinning

Polysynthetic on (100).

Type-locality form

Anhedral plates.

Comment

Space Group: Pcmn:

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
56BaBariumBarium1137.327137.327
50.21%
8OOxygenOxygen515.99979.995
29.25%
14SiSiliconSilicon228.08556.170
20.54%
Total273.492100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Al
  • Fe
  • Mg
  • Ca
  • Sr
  • H2O

In other languages

French
sanbornite
German
Sanbornit
Spanish
Sanbornita
Italian
Sanbornite

Classification

Strunz
10th ed.

9.EF.10

  • 9SilicatesClass
  • 9.EPhyllosilicatesDivision
  • 9.EFSingle nets with 6-membered rings, connected by M[4], M[8], etc.Group
  • 9.EF.10SanborniteSpecies
Dana
8th ed.

74.03.04.01

  • 74Phyllosilicates Modulated LayersClass
  • 74.03Modulated Layers with joined stripsType
  • 74.03.04Ba phyllosilicatesGroup
  • 74.03.04.01SanborniteSpecies
CIM

14.7.1

  • 14Silicates not Containing AluminumClass
  • 14.7Silicates of Ba, Sr and ZnGroup
  • 14.7.1SanborniteSpecies

Group, growth & confusion

Often grow together
2 minerals

Literature, links & citation

Citations
  1. 1932Rogers, Austin F. (1932) Sanbornite, a new barium silicate mineral from Mariposa County, California. American Mineralogist, 17 (5) 161-172
  2. 1932Bradley, W.W. (1932) Sanbornite, a newly described mineral from California. CA Min. Bur. Rept. 28: 82-83.
  3. 1954Douglass, R.M. (1954) Crystal structure of sanbornite (abstract). Geological Society of America Bulletin: 65: 1246.
  4. 1958Douglass, Robert M. (1958) The crystal structure of sanbornite, BaSi2O5. American Mineralogist, 43 (5-6) 517-536
  5. 1962Matthews, R.A., Alfors, J.T. (1962) Sanbornite from Rush Creek, Fresno County, Mineral Information Service, State of Ca Div. of Mines: 15(6): 1-3.
