Sarcopside

Fe2+3(PO4)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sar
Discovered
1868

Where it forms, where it's found

Geological setting

Granite pegmatite

Pegmatite

Type locality
Michałkowa pegmatites
  1. Gmina Świdnica
  2. Świdnica County
  3. Lower Silesian Voivodeship
  4. Poland

50.7500°, 16.4500°

49recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent · Opaque
Colour
Gray-pink · red-brown · brown (slightly altered) · blue · lavender · green · flesh-red in transmitted light · rarely white.
Tenacity
brittle
Cleavage
Distinct/Good

Distinct on a plane approximately perpendicular to the fibers, and another less distinct parallel to the fiber lenght (=[001] - ?).

Fracture
Splintery · Fibrous
Density
3.64 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 26 – 28° · 2V calc = 20 – 28°
Refractive index
1.67 – 1.734
Surface relief
High
Principal indices
nα 1.670 – 1.676 · nβ 1.728 – 1.730 · nγ 1.730 – 1.734
Birefringence
0.060
Dispersion
r > v perceptible
Extinction
Z=b, X^c = 45°
UV response
Not fluorescent in UV
Michel-Lévy diagramhighlighted lineδ = 0.0600
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]600 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation600 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/a
Cell parameters
a = 10.437(22) Å · b = 4.768(9) Å · c = 6.026(8) Å
Cell angles
β = 90.00(15) °
Ratio a:b:c
1 : 0.457 : 0.577
Z
2
Morphology

Irregular masses sometimes with a fibrous structure. May be configured into distorted six-sided plates (Silesia).

Twinning

Polysynthetic on (001), common.

Comment

Pseudo-orthorhombic.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
26FeIronIron355.845167.535
46.87%
8OOxygenOxygen815.999127.992
35.80%
15PPhosphorusPhosphorus230.97461.948
17.33%
Total357.475100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

In other languages

German
Sarkopsid
Italian
sarcopside

Classification

Strunz
10th ed.

8.AB.15

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.APhosphates, etc. without additional anions, without H2ODivision
  • 8.ABWith medium-sized cationsGroup
  • 8.AB.15SarcopsideSpecies
Dana
8th ed.

38.03.01.01

  • 38Anhydrous Normal Phosphates, Arsenates, and VanadatesClass
  • 38.03(AB)3(XO4)2Type
  • 38.03.01Sarcopside GroupGroup
  • 38.03.01.01SarcopsideSpecies
CIM

19.12.34

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.34SarcopsideSpecies

Group, growth & confusion

In the same group
2 members
Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1868Websky, M. (1868) Ueber Sarkopsid und Kochelit, zwei neue Minerale aus Schlesien. Zeitschrift der Deutschen Geologischen Gesellschaft, Berlin: 20: 245-257. (as Sarkopsid)
  2. 1920Holden, Edw. F. (1920) An American occurrence of sarcopside. American Mineralogist, 5 (5) 99-102
  3. 1924Holden, Edw. F. (1924) Further note on sarcopside. American Mineralogist, 9 (10) 205-206
  4. 1934Larsen, E.S.; Berman, H. (1934) The microscopic determination of the nonopaque minerals. Bulletin of the US Geological Survey Vol. 848. US Geological Survey p.1-266. doi:10.3133/b848 DOI: 10.3133/b848
  5. 1940Richmond, Wallace E. (1940) Crystal chemistry of the phosphates, arsenates and vanadates of the type A2XO4(Z). American Mineralogist, 25 (7). 441-479
