Scainiite

Pb14Sb30S54O5
IMA status
  • Approved
IMA symbol
Scn
IMA approved
1997
Also known as
  • IMA1996-014
  • Scainiiet
  • Scainit
  • +2 more

Where it forms, where it's found

Geological setting

Late extensional calcite veins embedded in the dolomitic limestones.

Type locality
Buca della Vena Mine
  1. Pontestazzemese
  2. Stazzema
  3. Lucca Province
  4. Tuscany
  5. Italy

43.9986°, 10.2944°

7recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Lustre
Metallic
Transparency
Opaque
Colour
Black · bluish metallic with dark red tint
Tenacity
brittle
Fracture
Irregular/Uneven
Density
5.56 g/cm³

Optical

Pleochroism
Not Visible
Optical colour
Black
Anisotropism
Weak
Bireflectance
Weak
Internal reflections
Rare red internal reflections
Tropism
Anisotropic
Reflectance R%
(37.5) 400, (38.0) 420, (37.6) 400, (37.6) 440, (37.6) 460, (37.0) 480, (36.6) 500, (36.2) 520, (35.6) 540, (35.4) 560, (34.7) 580, (34.1) 600, (33.4) 620, (32.8) 640, (32.4) 660, (32.0) 680, (31.1) 700, (30.9) 720, (30.2) 740, (29.8) 760, (29.2) 780, (29.8) 800
UV response
Not fluorescent
Reflected-light panel
34.1 %isotropic · single curve
Specimen sRGB 207, 149, 86
White reference100 % reflector under same lamp
Bireflectance
Weak
Anisotropism
Weak
Reflected colour
Black
Internal reflections
Rare red internal reflections

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 51.996(8) Å · b = 8.148(1) Å · c = 24.311(4) Å
Cell angles
β = 104.09(1) °
Ratio a:b:c
1 : 0.157 : 0.468
Unit cell volume
9991 ų
Z
4
Type-locality form

Acicular crystals, elongated [010], black in colour with bluish metallic luster. The bluish colour apparently arises from a superficial very low hydrothermal alteration of the crystals. Up to 2 mm long and 0.2 mm thick

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
51SbAntimonyAntimony30121.7603652.800
43.67%
82PbLeadLead14207.2002900.800
34.68%
16SSulfurSulfur5432.0601731.240
20.70%
8OOxygenOxygen515.99979.995
0.95%
Total8364.835100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1996-014
  • Scainiiet
  • Scainit
  • Scainita
  • Scainite

In other languages

German
IMA 1996-014 · Scainiit
Italian
scainiite

Classification

Strunz
10th ed.

2.JB.35b

  • 2Sulfides and SulfosaltsClass
  • 2.JSulfosalts of PbS archetypeDivision
  • 2.JBGalena derivatives, with PbGroup
  • 2.JB.35bScainiiteSpecies

Literature, links & citation

Citations
  1. 1985Makovicky, Emil (1985) Cyclically twinned sulphosalt structures and their approximate analogues. Zeitschrift für Kristallographie - Crystalline Materials, 173 (1-2). 1-23 doi:10.1524/zkri.1985.173.1-2.1 DOI: 10.1524/zkri.1985.173.1-2.1
  2. 1999Orlandi, Paolo, Moëlo, Yves, Meerschaut, Alain, Palvadeau, Pierre (1999) Lead-antimony sulfosalts from Tuscany (Italy) I. Scainiite, Pb14Sb30S54O5, the first Pb-Sb oxy-sulfosalt, from Buca della Vena mine. European Journal of Mineralogy, 11 (6) 949-954 doi:10.1127/ejm/11/6/0949 DOI: 10.1127/ejm/11/6/0949
  3. 2000Moëlo, Yves, Meerschaut, Alain, Orlandi, Paolo, Palvadeau, Pierre (2000) Lead-antimony sulfosalts from Tuscany (Italy): II - Crystal structure of scainiite, Pb14Sb30S54O5, an expanded monoclinic derivative of Ba12Bi24S48 hexagonal sub-type (zinkenite group) European Journal of Mineralogy, 12 (4) 835-846 doi:10.1127/0935-1221/2000/0012-0835 DOI: 10.1127/0935-1221/2000/0012-0835
  4. 2000Jambor, John L., Pertsev, Nikolai N., Roberts, Andrew C. (2000) New Mineral Names. American Mineralogist, 85. 1321-1325
  5. 2021(2021) Scainiite. Handbook of Mineralogy. Mineralogical Society of America
