Scheuchzerite

NaMn2+9Si9V5+O28(OH)4
IMA status
  • Approved
IMA symbol
Shz
IMA approved
2004
Also known as
  • IMA2004-044
  • Scheuchzeriet

Where it forms, where it's found

Geological setting

Manganese-bearing veins resulting from the remobilization of ore components during retrograde Tertiary Alpine metamorphism

Type locality
Fianel
  1. Ausserferrera
  2. Ferrera
  3. Viamala Region
  4. Grisons
  5. Switzerland

46.5464°, 9.4622°

4recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789102.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Yellow-orange
Streak
Yellow-orange
Cleavage
Distinct/Good
Density
3.5 g/cm³

Optical

Optical type
Biaxial (+)
Pleochroism
Weak

X: brown yellow Y: pale yellow

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 9.831 Å · b = 10.107 Å · c = 13.855 Å
Cell angles
α = 86.222 ° · β = 73.383 ° · γ = 71.987 °
Ratio a:b:c
1 : 1.028 : 1.409
Unit cell volume
1254.2 ų
Z
2
Type-locality form

acicular crystals up to 0.5 mm in length

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen3215.999511.968
38.29%
25MnManganeseManganese954.938494.442
36.98%
14SiSiliconSilicon928.085252.765
18.90%
23VVanadiumVanadium150.94250.942
3.81%
11NaSodiumSodium122.99022.990
1.72%
1HHydrogenHydrogen41.0084.032
0.30%
Total1337.139100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA2004-044
  • Scheuchzeriet

In other languages

German
IMA 2004-044 · Scheuchzerit
Italian
scheuchzerite

Classification

Strunz
10th ed.

9.DM.35

  • 9SilicatesClass
  • 9.DInosilicatesDivision
  • 9.DMInosilicates with 6-periodic single chainsGroup
  • 9.DM.35ScheuchzeriteSpecies

Literature, links & citation

Citations
  1. 2006Brugger, J. (2006) Scheuchzerite, Na(Mn,Mg)9[VSi9O28(OH)](OH)3, a new single-chain silicate. American Mineralogist, 91 (5) 937-943 doi:10.2138/am.2006.1965 DOI: 10.2138/am.2006.1965
  2. 2022(2022) Scheuchzerite. Handbook of Mineralogy. Mineralogical Society of America
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Scheuchzerite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/scheuchzerite-27490},
  note      = {Accessed 2026-05-11}
}
