Schneiderhöhnite

Fe2+Fe3+3As3+5O13
IMA status
  • Approved
IMA symbol
Snh
Discovered
1973
IMA approved
1973
Also known as
  • IMA1973-046
  • Schneiderhöhniet

Where it forms, where it's found

Geological setting

Deep oxidation zone.

Type locality
Tsumeb Mine (Ongopolo Mine)
  1. Tsumeb
  2. Oshikoto Region
  3. Namibia

-19.2270°, 17.7276°

12recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Usually black to blackish brown
Streak
Brown
Tenacity
brittle
Cleavage
Perfect

(100) perfect; two others distinct.

Fracture
Micaceous
Density
4.3 g/cm³

Optical

Optical type
Biaxial (+)
Refractive index
2.11 – 2.13
Surface relief
Very high
Principal indices
nα 2.11 · nγ 2.13
Birefringence
<0.02
Pleochroism
Strong

Reddish-brown to bright yellow.

Anisotropism
Weak, greenish to brownish.
Bireflectance
Not apparent.
Internal reflections
Reddish brown.
Tropism
Anisotropic
UV response
Not fluorescent.
Notes

Refractive indices are >2.11 and <2.13. Absorption: X > Y < Z. Reflectance lower than chalcocite.

Michel-Lévy diagramhighlighted lineδ = 0.0200
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]200 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation200 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
P-1
Cell parameters
a = 8.945(3) Å · b = 10.022(3) Å · c = 9.161(4) Å
Cell angles
α = 62.942(5) ° · β = 116.072(6) ° · γ = 81.722(6) °
Ratio a:b:c
1 : 1.120 : 1.024
Z
2
Type-locality form

Druses, with aggregates of crystals up to 7 mm.

Comment

Cooper and Hawthorne, 2016. Refined to R1=1.4%.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
33AsArsenicArsenic574.922374.610
46.48%
26FeIronIron455.845223.380
27.71%
8OOxygenOxygen1315.999207.987
25.81%
Total805.977100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1973-046
  • Schneiderhöhniet

In other languages

German
IMA 1973-046 · Schneiderhöhnit
Italian
Schneiderhöhnite

Classification

Strunz
10th ed.

4.JA.35

  • 4OxidesClass
  • 4.JArsenites, antimonites, bismuthites, sulfites, selenites, tellurites; iodatesDivision
  • 4.JAArsenites, antimonites, bismuthites; without additional anions, without H2OGroup
  • 4.JA.35SchneiderhöhniteSpecies
Dana
8th ed.

45.01.12.01

  • 45Acid and Normal Antimonites and ArsenitesClass
  • 45.01MiscellaneousType
  • 45.01.12— unnamed intermediate level —Group
  • 45.01.12.01SchneiderhöhniteSpecies
CIM

23.19

  • 23ArsenitesClass
  • 23.19— unnamed intermediate level —Group
  • 23.19SchneiderhöhniteSpecies

Literature, links & citation

Citations
  1. 1973Ottemann, J., Nuber, B., Geier, B. H. (1973) Schneiderhöhnit, ein natürliches Eisen-Arsen-Oxid aus der tiefen Oxidationszone von Tsumeb. Neues Jahrbuch für Mineralogie - Monatshefte, 1973. 517-523
  2. 1974Fleischer, Michael (1974) New mineral names. American Mineralogist, 59 (9-10). 1139-1141
  3. 1980Schmetzer, K., Tremmel, G., Bartelke, W. (1980) Eine Paragenese seltener Minerale aus Bou-Azzer, Marokko: Parasymplesit, Symplesit, Schneiderhöhnit, Karibibit. Neues Jahrbuch für Mineralogie, Abhandlungen: 138: 94-108.
  4. 1985Hawthorne, F. C. (1985): Schneiderhöhnite, Fe2+Fe3+3As3+5O13, a densely packed arsenite structure. The Canadian Mineralogist, 23, 675-679.
  5. 1987Hawthorne, Frank C., Jambor, John L., Bladh, Kenneth W., Burke, Ernst A. J., Grice, Joel D., Phillips, Don, Roberts, Andrew C., Schedler, Robert A., E., James (1987) New mineral names. American Mineralogist, 72 (9-10) 1023-1028
