Schreyerite

V3+2Ti4+3O9
IMA status
  • Approved
IMA symbol
Sry
Discovered
1976
IMA approved
1976
Also known as
  • IMA1976-004
  • Schreyeriet

Where it forms, where it's found

Geological setting

Intergrowths with rutile in highly metamorphosed gneiss.

Type locality
Lasamba Hill
  1. Kwale County
  2. Kenya

-4.1667°, 38.6331°

14recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789107/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Reddish brown
Density
4.46 g/cm³

Optical

Optical type
Biaxial
Refractive index
2.7
Surface relief
Very high
Principal indices
nα 2.7
Pleochroism
Weak

yellow-brown to reddish brown.

Dispersion
relatively strong
Optical colour
Gray
Anisotropism
Moderate
Bireflectance
White to brownish
Internal reflections
None
Tropism
Anisotropic
Notes

The mean value of reflectivity for 546 nm (Na light) is 21%.

Crystallography

Crystal system
Monoclinic
Space group
C2/c
Cell parameters
a = 17.102(2) Å · b = 5.0253(5) Å · c = 7.0579(8) Å
Cell angles
β = 106.636(10) °
Ratio a:b:c
1 : 0.294 : 0.413
Z
4
Morphology

Occurs in intergrowth with rutile.

Twinning

Very fine polysynthetic twinning.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
36.97%
22TiTitaniumTitanium347.867143.601
36.87%
23VVanadiumVanadium250.942101.884
26.16%
Total389.476100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1976-004
  • Schreyeriet

In other languages

French
Schreyerite
German
IMA 1976-004 · Schreyerit
Italian
Schreyerite

Classification

Strunz
10th ed.

4.CB.35

  • 4OxidesClass
  • 4.CMetal: Oxygen = 2: 3,3: 5, and similarDivision
  • 4.CBWith medium-sized cationsGroup
  • 4.CB.35SchreyeriteSpecies
Dana
8th ed.

08.04.01.01

  • 08Multiple Oxides Containing Niobium, Tantalum or TitaniumClass
  • 08.04A2B3O9Type
  • 08.04.01Schreyerite GroupGroup
  • 08.04.01.01SchreyeriteSpecies
CIM

7.12.14

  • 7Oxides and HydroxidesClass
  • 7.12Oxides of V, Nb and TaGroup
  • 7.12.14SchreyeriteSpecies

Group, growth & confusion

Commonly confused with
1 mineral

Literature, links & citation

Citations
  1. 1976Medenbach, O., Schmetzer, K. (1976) Schreyerit (V2Ti3O9), ein neues Vanadium-Mineral aus Kenya. Die Naturwissenschaften, 63 (6). 293-294 doi:10.1007/bf00624019DOI: 10.1007/bf00624019
  2. 1977Fleischer, Michael, Jambor, John (1977) New mineral names. American Mineralogist, 62 (3-4).
  3. 1978Medenbach, Olaf, Schmerzer, Karl (1978) Schreyerite, V2Ti3O9, a new mineral. American Mineralogist, 63 (11-12) 1182-1186
  4. 1982Zakrzewski, M. A., Burke, E. A. J., Lustenhouwer, W. J. (1982) Vuorelainenite, a new spinel, and associated minerals from the Satra (Doverstorp) pyrite deposit, central Sweden. The Canadian Mineralogist, 20 (2) 281-290
  5. 1983Bernhardt, H. J., Schmetzer, K., Medenbach, O. (1983) Berdesinskiite, V2TiO5, a new mineral from Kenya and additional data for schreyerite, V2Ti3O9. Neues Jahrbuch für Mineralogie - Monatshefte, 1983. 110-118
