Scrutinyite

PbO2
IMA status
  • Approved
IMA symbol
Sny
Discovered
1988
Also known as
  • IMA1984-061
  • Scrutinyiet

Where it forms, where it's found

Geological setting

Oxidation product of hydrothermal mineralization.

Type locality
Sunshine No. 1 Adit
  1. Blanchard Mine
  2. Bingham
  3. Hansonburg District
  4. Socorro County
  5. New Mexico
  6. USA

33.8117°, -106.3750°

8recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Transparency
Translucent · Opaque
Colour
Dark reddish brown · clove-brown · red on thin edges
Streak
Dark brown
Cleavage
Perfect

(100), perfect; (010), imperfect (forms by analogy to columbite).

Density
9.867 g/cm³

Optical

Pleochroism
Not Visible
Optical colour
Grey-white
Anisotropism
Weak with a bluish color
Bireflectance
Very weak, grey-white to bluish grey-white
Internal reflections
Reddish brown
Tropism
Anisotropic
Reflectance R%
(17.9,18.8) 546, (17.0,17.9) 589
UV response
Not fluorescent.
Reflected-light panel
17.4 %anisotropic · dual curve
Specimen sRGB 153, 108, 59
White reference100 % reflector under same lamp
R₁ R₂
Mode
Bireflectance
Very weak, grey-white to bluish grey-white
Anisotropism
Weak with a bluish color
Reflected colour
Grey-white
Internal reflections
Reddish brown

Crystallography

Crystal system
Orthorhombic
Space group
#63
Cell parameters
a = 4.971(2) Å · b = 5.956(2) Å · c = 5.438(2) Å
Ratio a:b:c
1 : 1.198 : 1.094
Z
4
Morphology

Tabular crystals up to 30 micron.

Type-locality form

Euhedral crystals 25-30 microns across and 1-2 microns thick.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead1207.200207.200
86.62%
8OOxygenOxygen215.99931.998
13.38%
Total239.198100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1984-061
  • Scrutinyiet

In other languages

German
IMA 1984-061 · Scrutinyit
Italian
Scrutinyite
Japanese
Scrutinyite

Classification

Strunz
10th ed.

4.DB.20

  • 4OxidesClass
  • 4.DMetal: Oxygen = 1:2 and similarDivision
  • 4.DBWith medium-sized cations; chains of edge-sharing octahedraGroup
  • 4.DB.20ScrutinyiteSpecies
Dana
8th ed.

04.04.06.02

  • 04Simple OxidesClass
  • 04.04AX2Type
  • 04.04.06— unnamed intermediate level —Group
  • 04.04.06.02ScrutinyiteSpecies
CIM

7.11.24

  • 7Oxides and HydroxidesClass
  • 7.11Oxides of Sn and PbGroup
  • 7.11.24ScrutinyiteSpecies

Group, growth & confusion

Commonly confused with
2 minerals

Literature, links & citation

Citations
  1. 1952Zaslavskii, A.I., Tolkachev, S.S. (1952) The structure of the α-modification of lead dioxide. Zhurnal Fizicheskoi Khimii, 26, 743-752.
  2. 1988Taggart, J.E., Foord, E.E., Rosenzweig, A., Hanson, T. (1988) Scrutinyite, natural occurrences of αPbO2 from Bingham, New Mexico, U.S.A., and Mapimi, Mexico. The Canadian Mineralogist, 26, 905-910. https://www.rruff.net/odr/view/downloadfile/66798
  3. 1990Jambor, John L., Vanko, David A. (1990) New Mineral Names. American Mineralogist, 75 (5-6) 706-713
  4. 1994Nekrasov, I.Y. (1994) Scrutinyite, α-PbO2, its second find in the world. Transactions of the Russian Academy of Sciences, Earth Science Sections, 324(4), 150-153.
  5. 2005(2005) Scrutinyite. Handbook of Mineralogy. Mineralogical Society of America
