Seeligerite

Pb3(IO4)Cl3
IMA status
  • Approved
IMA symbol
Sli
Also known as
  • IMA1970-036
  • Seeligeriet

Where it forms, where it's found

Type locality
Santa Ana Mine
  1. Caracoles
  2. Caracoles mining district
  3. Sierra Gorda
  4. Antofagasta Province
  5. Antofagasta
  6. Chile
5recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Colour
Bright yellow
Cleavage
Perfect

(001) perfect, (110) good, (100) and (010) rare

Optical

Optical type
Biaxial (-) · 2V measured = 4°
Refractive index
2.12 – 2.32
Surface relief
Very high
Principal indices
nα 2.12 · nβ 2.32 · nγ 2.32
Dispersion
r < v
Michel-Lévy diagramhighlighted lineδ = 0.2000
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]2000 nm4th order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation2000 nm
Order4th order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#22
Cell parameters
a = 7.971(2) Å · b = 7.976(2) Å · c = 27.341(5) Å
Ratio a:b:c
1 : 1.001 : 3.430
Unit cell volume
1738.3 ų
Z
8
Morphology

Thin plates

Type-locality form

Thin plates

Comment

The TEM investigation has revealed additional superlattice reflections.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead3207.200621.600
67.65%
53IIodineIodine1126.904126.904
13.81%
17ClChlorineChlorine335.450106.350
11.57%
8OOxygenOxygen415.99963.996
6.97%
Total918.850100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1970-036
  • Seeligeriet

In other languages

French
Seeligerite
German
IMA 1970-036 · Seeligerit
Spanish
Seeligerita
Italian
seeligerite

Classification

Strunz
10th ed.

4.KB.15

  • 4OxidesClass
  • 4.KIodates: Trigonal [IO3] pyramids (mostly).Division
  • 4.KBIodates with additional anions, without H2OGroup
  • 4.KB.15SeeligeriteSpecies
Dana
8th ed.

22.01.02.01

  • 22Iodates Containing Hydroxyl or HalogenClass
  • 22.01MiscellaneousType
  • 22.01.02— unnamed intermediate level —Group
  • 22.01.02.01SeeligeriteSpecies
CIM

29.6

  • 29IodatesClass
  • 29.6— unnamed intermediate level —Group
  • 29.6SeeligeriteSpecies

Literature, links & citation

Citations
  1. 1971Mücke, A. (1971) Seeligerit, ein natürliches Blei-Jodat. Neues Jahrbuch für Mineralogie, Monatshefte: 1971: 210-217.
  2. 1972Fleischer, Michael (1972) New Mineral Names. American Mineralogist, 57 (1-2) 325-329
  3. 2005(2005) Seeligerite. Handbook of Mineralogy. Mineralogical Society of America
  4. 2008Bindi, L., Welch, M. D., Bonazzi, P., Pratesi, G., Menchetti, S. (2008) The crystal structure of seeligerite, Pb3IO4Cl3, a rare Pb-I-oxychloride from the San Rafael mine, Sierra Gorda, Chile. Mineralogical Magazine, 72 (3) 771-783 doi:10.1180/minmag.2008.072.3.771DOI: 10.1180/minmag.2008.072.3.771
