Selwynite

NaKBeZr2(PO4)4 · 2H2O
IMA status
  • Approved
IMA symbol
Swy
Discovered
1995
Also known as
  • IMA1993-037
  • Potassian Gainesite
  • Selwyniet

Where it forms, where it's found

Type locality
Wycheproof granite quarry
  1. Wycheproof
  2. Buloke Shire
  3. Victoria
  4. Australia

-36.0764°, 143.2347°

1recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Lustre
Vitreous
Transparency
Transparent · Translucent
Colour
Deep purplish blue

may be pale lavender if weathered.

Streak
Lavender, pale
Fracture
Sub-Conchoidal
Density
3.08 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.624 – 1.636
Surface relief
Moderate
Principal indices
nω 1.624 · nε 1.636
Pleochroism
Visible

O = medium bluish lavender; E = very pale bluish lavender.

Michel-Lévy diagramhighlighted lineδ = 0.0120
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]120 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation120 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
I41/amd
Cell parameters
a = 6.570(3) Å · c = 17.142(6) Å
Z
2
Type-locality form

anhedral, indistinct, in radiating groups

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1815.999287.982
43.02%
40ZrZirconiumZirconium291.224182.448
27.25%
15PPhosphorusPhosphorus430.974123.896
18.51%
19KPotassiumPotassium139.09839.098
5.84%
11NaSodiumSodium122.99022.990
3.43%
4BeBerylliumBeryllium19.0129.012
1.35%
1HHydrogenHydrogen41.0084.032
0.60%
Total669.458100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Rb
  • Ca
  • Sr
  • Ba
  • Mg
  • Mn
  • Fe
  • Cs
  • Ce
  • Hf
  • P
  • Si
  • F

Synonyms

  • IMA1993-037
  • Potassian Gainesite
  • Selwyniet

In other languages

German
IMA 1993-037 · Selwynit
Italian
IMA1993-037 · selwynite

Classification

Strunz
10th ed.

8.CA.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CAWith small and large/medium cationsGroup
  • 8.CA.20SelwyniteSpecies
Dana
8th ed.

40.05.04.03

  • 40Hydrated Normal Phosphates, Arsenates and VanadatesClass
  • 40.05AXO4·xH2OType
  • 40.05.04Gainesite GroupGroup
  • 40.05.04.03SelwyniteSpecies

Group, growth & confusion

In the same group
2 members

Literature, links & citation

Citations
  1. 1993Birch, W. D., Henry, D. A. - Eds. (1993) Phosphate Minerals of Victoria. Special Publication 3. Mineralogical Society of Victoria
  2. 1995Birch, W. D., Pring, A., Foord, E. E. (1995) Selwynite, NaK(Be,Al)Zr2(PO4)4 · 2H2O, a new gainesite-like mineral from Wycheproof, Victoria, Australia. The Canadian Mineralogist, 33 (1) 55-58
  3. 1996Mandarino, Joseph A. (1996) Abstracts of New Mineral Descriptions. The Mineralogical Record, 27 (2) 115-120
  4. 2005(2005) Selwynite. Handbook of Mineralogy. Mineralogical Society of America
Cite this entry
@misc{mineral2026,
  author    = {Mineral Index editorial board},
  title     = {Selwynite — Mineral Index},
  year      = {2026},
  url       = {https://mineralindex.org/minerals/selwynite-7287},
  note      = {Accessed 2026-05-11}
}
