Shortite

Na2Ca2(CO3)3
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sot
Discovered
1939
Also known as
  • Shortiet

Where it forms, where it's found

Geological setting

From a drill core in Eocene clay and oil shale.

Type locality
John Hay Jr. Well No. 1
  1. Sweetwater County
  2. Wyoming
  3. USA

41.5681°, -109.8006°

42recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless · light yellow · light green
Streak
White
Cleavage
Distinct/Good

On (010).

Fracture
Conchoidal
Density
2.6 g/cm³

Optical

Optical type
Biaxial (-)
Refractive index
1.531 – 1.57
Surface relief
Moderate
Principal indices
nα 1.531 · nβ 1.555 · nγ 1.57
Dispersion
r < v moderate
Extinction
Parallel. X = c; Y = a; Z = b.
UV response
Fluoresces pale amber (UV).
Michel-Lévy diagramhighlighted lineδ = 0.0390
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]390 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation390 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
#19
Cell parameters
a = 4.96 Å · b = 11.03 Å · c = 7.12 Å
Ratio a:b:c
1 : 2.224 : 1.435
Morphology

Crystals wedge-shaped, tabular (100) or equant to short prismatic [100]. (011) striated [100] and in oscillatory combination with (001).

Type-locality form

Nearly equant crystals from 1-3 millimeters in size, and tabular crystals up to 15 millimeters across and 2-3 millimeters thick.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen915.999143.991
47.03%
20CaCalciumCalcium240.07880.156
26.18%
11NaSodiumSodium222.99045.980
15.02%
6CCarbonCarbon312.01136.033
11.77%
Total306.160100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Shortiet

In other languages

German
Shortit
Spanish
Shortita
Italian
Shortite

Classification

Strunz
10th ed.

5.AC.25

  • 5CarbonatesClass
  • 5.ACarbonates without additional anions, without H2ODivision
  • 5.ACAlkali and alkali-earth carbonatesGroup
  • 5.AC.25ShortiteSpecies
Dana
8th ed.

14.04.01.01

  • 14Anhydrous Normal CarbonatesClass
  • 14.04MiscellaneousType
  • 14.04.01— unnamed intermediate level —Group
  • 14.04.01.01ShortiteSpecies
CIM

11.1.9

  • 11CarbonatesClass
  • 11.1Carbonates of the alkali metals and ammoniumGroup
  • 11.1.9ShortiteSpecies

Group, growth & confusion

Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1939Fahey, Joseph J. (1939) Shortite, a new carbonate of sodium and calcium. American Mineralogist, 24 (8) 514-518
  2. 1941Richmond, W. E. (1941) X-ray crystallography of shortite. American Mineralogist, 26 (4) 288-289
  3. 1941Richmond, W.E. (1941) Shortite: correction of space group. American Mineralogist: 26: 629-629.
  4. 1950Wickman, Frans E. (1950) The crystal structure of Shortite, Ca2Na2(CO3)3. Arkiv för Mineralogi och Geologi, 1 (2). 95-101
  5. 1951Palache, Charles; Berman, Harry; Frondel, Clifford (1951) The System of Mineralogy (7th ed.) Vol. 2 - Halides, Nitrates, Borates, Carbonates, Sulfates, Phosphates, Arsenates, Tungstates, Molybdates, Etc. John Wiley and Sons.
