Shuiskite-(Mg)

Ca2MgCr2(Si2O7)(SiO4)(OH)2 · H2O
IMA status
  • Approved
IMA symbol
Sui-Mg
Discovered
1980
IMA approved
1980
Also known as
  • IMA1980-061
  • Shuiskiet-(Mg)
  • Shuiskit

Where it forms, where it's found

Type locality
Biserskoye Cr deposit (Biserskii Zavod
  1. Bissersky)
  2. Gornozavodskii District
  3. Perm Krai
  4. Russia
2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789106/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Translucent
Colour
Dark brown with a violet tint
Streak
light greenish brown
Cleavage
Perfect

(001)

Density
3.24 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 40 – 50° · 2V calc = 30 – 46°
Refractive index
1.725 – 1.775
Surface relief
High
Principal indices
nα 1.725 – 1.733 · nβ 1.762 – 1.772 · nγ 1.769 – 1.775
Pleochroism
Strong

X = blue-violet; Y = yellowish green; Z = dark violet

Dispersion
r < v strong
Michel-Lévy diagramhighlighted lineδ = 0.0430
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]430 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation430 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 8.89 Å · b = 5.84 Å · c = 19.41 Å
Cell angles
β = 98 °
Ratio a:b:c
1 : 0.657 : 2.183
Z
4
Morphology

radiating aggregates of ¯brous prismatic crystals, to 1 cm.

Comment

Space Group: A2/m:

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1415.999223.986
43.01%
24CrChromiumChromium251.996103.992
19.97%
14SiSiliconSilicon328.08584.255
16.18%
20CaCalciumCalcium240.07880.156
15.39%
12MgMagnesiumMagnesium124.30524.305
4.67%
1HHydrogenHydrogen41.0084.032
0.78%
Total520.726100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Ti
  • Fe
  • Mn
  • Na
  • K
  • H20

Synonyms

  • IMA1980-061
  • Shuiskiet-(Mg)
  • Shuiskit

In other languages

German
IMA 1980-061 · Shuiskit · Shuiskit-(Mg)
Italian
Shuiskite

Classification

Strunz
10th ed.

9.BG.20

  • 9SilicatesClass
  • 9.BSorosilicatesDivision
  • 9.BGSorosilicates with mixed SiO4 and Si2O7 groups; cations in octahedral [6] and greater coordinationGroup
  • 9.BG.20Shuiskite-(Mg)Species
Dana
8th ed.

58.02.02.09

  • 58Sorosilicates Insular, Mixed, Single, and Larger Tetrahedral GroupsClass
  • 58.02Insular, Mixed, Single, and Larger Tetrahedral Groups with cations in [6] and higher coordination; single and double groups (n = 1, 2)Type
  • 58.02.02Pumpellyite groupGroup
  • 58.02.02.09Shuiskite-(Mg)Species
CIM

16.15.5

  • 16Silicates Containing Aluminum and other MetalsClass
  • 16.15Aluminosilicates of V and CrGroup
  • 16.15.5Shuiskite-(Mg)Species

Group, growth & confusion

In the same group
1 members

Literature, links & citation

Citations
  1. 1981Ivanov, O.K., V.A. Arkhangel'skaya, L.O. Miroshnikova, and T.A. Shilova (1981) Shuiskite, the chromium analog of pumpellyite, from the Bisersk deposit, Urals. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva: 110: 508-512. [Abs. in American Mineralogist (1982): 67: 860.]
  2. 1981Ivanov, O.K., V.A. Arkhangel'skaya, L.O. Miroshnikova, and T.A. Shilova (1981) Shuiskite, the chromium analog of pumpellyite, from the Bisersk deposit, Urals. Zapiski Vserossiyskogo Mineralogicheskogo Obshchestva: 110: 508-512.
  3. 1985Ivanov, O. K.; Kainov, V. I.; Malinovskii, Yu. A. (1985) Variety of shuiskite with low water content from the Saranov chromite mine, Urals. Zapiski Vsesoyuznogo Mineralogicheskogo Obshchestva: 114: 49-55.
  4. 2010Nagashima, Mariko, Armbruster, Thomas, Libowitzky, Eugen (2010) The hydrogen-bond system in pumpellyite. European Journal of Mineralogy, 22 (3) 333-342 doi:10.1127/0935-1221/2010/0022-2033DOI: 10.1127/0935-1221/2010/0022-2033
  5. 2018Lykova, Inna S., Varlamov, Dmitry A., Chukanov, Nikita V., Pekov, Igor V., Zubkova, Natalia V. (2018) Crystal chemistry of shuiskite and chromian pumpellyite-(Mg) European Journal of Mineralogy, 30 (6) 1133-1139 doi:10.1127/ejm/2018/0030-2789DOI: 10.1127/ejm/2018/0030-2789
