Simonkolleite

Zn5(OH)8Cl2 · H2O
IMA status
  • Approved
IMA symbol
Skl
Discovered
1983
IMA approved
1983
Also known as
  • IMA1983-019
  • Simonkolleiet

Where it forms, where it's found

Geological setting

Originally found as a weathering product of zn-bearing slags at the Richelsdorf Smelting Refinery.

Type locality
Slag dumps
  1. Richelsdorf Smelter
  2. Süß
  3. Nentershausen
  4. Hersfeld-Rotenburg
  5. Kassel Region
  6. Hesse
  7. Germany
13recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789101.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless
Streak
White
Tenacity
brittle
Cleavage
Perfect

(0001)

Density
3.20 g/cm³

Optical

Optical type
Uniaxial (+)
Refractive index
1.657 – 1.7
Surface relief
High
Principal indices
nω 1.657 · nε 1.700
Birefringence
0.043
Pleochroism
Non-pleochroic
Michel-Lévy diagramhighlighted lineδ = 0.0430
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]430 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation430 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
#97
Cell parameters
a = 6.34 Å · c = 23.66 Å
Z
3
Type-locality form

Tabular hexagonal crystals to 1 mm

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
30ZnZincZinc565.380326.900
59.23%
8OOxygenOxygen915.999143.991
26.09%
17ClChlorineChlorine235.45070.900
12.85%
1HHydrogenHydrogen101.00810.080
1.83%
Total551.871100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1983-019
  • Simonkolleiet

In other languages

German
IMA 1983-019 · Simonkolleit
Italian
Simonkolleite

Classification

Strunz
10th ed.

3.DA.20

  • 3HalidesClass
  • 3.DOxyhalides, hydroxyhalides and related double halidesDivision
  • 3.DAWith Cu, etc., without PbGroup
  • 3.DA.20SimonkolleiteSpecies
Dana
8th ed.

10.05.08.01

  • 10Oxyhalides and HydroxyhalidesClass
  • 10.05Am(O,OH)pXqType
  • 10.05.08— unnamed intermediate level —Group
  • 10.05.08.01SimonkolleiteSpecies
CIM

8.5.1

  • 8Halides - Fluorides, Chlorides, Bromides and Iodides; also Fluoborates and FluosilicatesClass
  • 8.5Halides of Zn and HgGroup
  • 8.5.1SimonkolleiteSpecies

Literature, links & citation

Citations
  1. 1968Allmann, Rudolf (1968) Verfeinerung der Struktur des Zinkhydroxidchlorids II, Zn5(OH)8Cl2· 1H2O. Zeitschrift für Kristallographie, 126 (5-6). 417-426 doi:10.1524/zkri.1968.126.5-6.417 DOI: 10.1524/zkri.1968.126.5-6.417
  2. 1985Schmetzer, K., Schnorrer-Köhler, G., Medenbach, O. (1985) Wülfingite, ε-Zn(OH)2, and simonkolleite, Zn(OH)8Cl2•H2O, two new minerals from Richelsdorf, Hesse, R. F. G. Neues Jahrbuch für Mineralogie - Monatshefte, 1985. 145-154
  3. 1988American Mineralogist (1988): 73: 194-195.
  4. 2002Hawthorne, F. C.; Sokolova, E. (2002) Simonkolleite, Zn5(OH)8Cl2(H2O), a decorated interrupted-sheet structure of the form [MΦ2]4. The Canadian Mineralogist, 40 (3). 939-946 doi:10.3749/gscanmin.40.3.939 DOI: 10.3749/gscanmin.40.3.939
  5. 2007(2007) Simonkolleite. Handbook of Mineralogy. Mineralogical Society of America
