Sinkankasite

Mn2+Al(PO3OH)2(OH) · 6H2O
IMA status
  • Approved
IMA symbol
Ska
IMA approved
1982
Also known as
  • IMA1982-078
  • Sinkankasiet

Where it forms, where it's found

Geological setting

Late-stage hydrothermal alteration product of triphylite.

Type locality
Barker-Ferguson Mine
  1. Keystone
  2. Keystone Mining District
  3. Pennington County
  4. South Dakota
  5. USA

43.8803°, -103.3681°

3recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent
Colour
Colourless
Tenacity
very brittle
Cleavage
Perfect

(100)

Density
2.27 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 84° · 2V calc = 84°
Refractive index
1.511 – 1.544
Surface relief
Moderate
Principal indices
nα 1.511 · nβ 1.529 · nγ 1.544
Dispersion
r < v, moderate.
Extinction
Y ∧ c ≃ 11°.
UV response
Not fluorescent.
Notes

Optical measurements are complicated by intrinsic multiple twinning.

Michel-Lévy diagramhighlighted lineδ = 0.0330
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]330 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation330 nm
Order1st order
XPL colour

Crystallography

Crystal system
Triclinic
Space group
#2
Cell parameters
a = 9.590(2) Å · b = 9.818(2) Å · c = 6.860(1) Å
Cell angles
α = 108.04(3) ° · β = 99.63(3) ° · γ = 98.87(3) °
Ratio a:b:c
1 : 1.024 : 0.715
Z
2
Morphology

Elongate on [001], tabular on (100) and composed of the forms (100), (010), and (001).

Twinning

On (100), common.

Parting
Parting along (100) twin boundaries.
Type-locality form

Complete pseudomorphs after subhedral to euhedral triphylite and as cavity fillings formed from the partial or complete dissolution of triphylite; ranging in size from <1 to 10 cm3. Also found along fractures that cut quartz, microcline, albite, and muscovite.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen1515.999239.985
60.15%
15PPhosphorusPhosphorus230.97461.948
15.53%
25MnManganeseManganese154.93854.938
13.77%
13AlAluminiumAluminium126.98226.982
6.76%
1HHydrogenHydrogen151.00815.120
3.79%
Total398.973100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1982-078
  • Sinkankasiet

In other languages

French
sinkankasite
German
IMA 1982-078 · Sinkankasit
Italian
Sinkankasite

Classification

Strunz
10th ed.

8.DB.20

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.DPhosphates, etc. with additional anions, with H2ODivision
  • 8.DBWith only medium-sized cations, (OH, etc.):RO4< 1:1Group
  • 8.DB.20SinkankasiteSpecies
Dana
8th ed.

42.07.01.04

  • 42Hydrated Phosphates, Etc.containing Hydroxyl or HalogenClass
  • 42.07(AB)2(XO4)Zq·xH2OType
  • 42.07.01Childrenite GroupGroup
  • 42.07.01.04SinkankasiteSpecies
CIM

19.12.8

  • 19PhosphatesClass
  • 19.12Phosphates of MnGroup
  • 19.12.8SinkankasiteSpecies

Literature, links & citation

Citations
  1. 1984Peacor, Donald R., Dunn, Pete J., Roberts, Willard L., Campbell, Thomas J., Simmons, William B. (1984) Sinkankasite, a new phosphate from the Barker pegmatite, South Dakota. American Mineralogist, 69 (3-4) 380-382
  2. 1995Burns, Peter C., Hawthorne, Frank C. (1995) The crystal structure of sinkankasite, a complex heteropolyhedral sheet mineral. American Mineralogist, 80 (5) 620-627 doi:10.2138/am-1995-5-620 DOI: 10.2138/am-1995-5-620
  3. 2005(2005) Sinkankasite. Handbook of Mineralogy. Mineralogical Society of America
