Soddyite

(UO2)2(SiO4)(H2O)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sod
Discovered
1922
Also known as
  • Soddite
  • Soddyiet

Where it forms, where it's found

Type locality
Shinkolobwe Mine
  1. Shinkolobwe
  2. Kambove Territory
  3. Haut-Katanga
  4. DR Congo

-11.0486°, 26.5508°

48recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789103 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent · Opaque
Colour
Canary-yellow · amber-yellow
Streak
Pale yellow
Cleavage
Perfect

Perfect on (001), good on (111)

Density
4.63 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 70 – 84°
Refractive index
1.65 – 1.715
Surface relief
High
Principal indices
nα 1.65 – 1.654 · nβ 1.685 · nγ 1.699 – 1.715
Pleochroism
Weak

X = colorless; Y = very pale yellow; Z = pale yellow-green

Dispersion
r > v; negligible to strong
Michel-Lévy diagramhighlighted lineδ = 0.0550
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]550 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation550 nm
Order1st order
XPL colour

Crystallography

Crystal system
Orthorhombic
Space group
Fddd
Cell parameters
a = 8.3097(3) Å · b = 11.2205(4) Å · c = 18.6576(11) Å
Ratio a:b:c
1 : 1.350 : 2.245
Type-locality form

Minute prismatic crystals.

Comment

Cell parameters from Plášil (2018) with R1=1.92%.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium2238.029476.058
71.25%
8OOxygenOxygen1015.999159.990
23.95%
14SiSiliconSilicon128.08528.085
4.20%
1HHydrogenHydrogen41.0084.032
0.60%
Total668.165100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Soddite
  • Soddyiet

In other languages

German
Soddyit
Spanish
Soddyita
Italian
soddyite

Classification

Strunz
10th ed.

9.AK.05

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AKUranyl neso- and polysilicatesGroup
  • 9.AK.05SoddyiteSpecies
Dana
8th ed.

53.03.03.01

  • 53Nesosilicates Insular Sio4 Groups and Other Anions or Complex CationsClass
  • 53.03Insular SiO4 Groups and Other Anions of Complex Cations with (UO2)Type
  • 53.03.03Other uranyl sillicatesGroup
  • 53.03.03.01SoddyiteSpecies
CIM

14.16.3

  • 14Silicates not Containing AluminumClass
  • 14.16Silicates of UGroup
  • 14.16.3SoddyiteSpecies

Literature, links & citation

Citations
  1. 1922Wherry, E.T., Holden, E.F. (1922) New minerals - new species. American Mineralogist: 7: 178-180.
  2. 1922Schoep, A. (1922) La soddite, nouveau minéral radioactif. Comptes rendus hebdomadaires des séances de l'Académie des sciences de Paris: 174: 1066-1067 (soddyite, as soddite) (in French). https://gallica.bnf.fr/ark:/12148/bpt6k3127j/f1067.item
  3. 1952Gorman, D. H. (1952) Studies of radioactive compounds: V--Soddyite. American Mineralogist, 37 (5-6) 386-393
  4. 1979Belokoneva, E.L., Mokeeva, V.I., Kuznetsov, L.M., Simonov, M.A., Makarov, E.S., Belov, N.V.E. (1979) Crystal structure of synthetic soddyite (UO2)2[SiO4](H2O)2. Doklady Akademii Nauk SSSR: 246(1): 93-96.
  5. 1981Stohl, Frances V., Smith, Deane K. (1981) The crystal chemistry of the uranyl silicate minerals. American Mineralogist, 66 (5-6) 610-624
