Sorbyite

Pb9Cu(Sb,As)11S26
IMA status
  • Approved
IMA symbol
Srb
Discovered
1966
IMA approved
1966
Also known as
  • IMA1966-031
  • IMA1966-032
  • Sorbyiet

Where it forms, where it's found

Geological setting

Hydrothermal

Type locality
Taylor Pit
  1. Madoc
  2. Centre Hastings Municipality
  3. Hastings County
  4. Ontario
  5. Canada

44.5022°, -77.4664°

6recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789103.5 – 4/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Lead gray
Streak
Black
Cleavage
Perfect

on (001)

Density
5.52 g/cm³

Optical

Pleochroism
Strong
Optical colour
White
Anisotropism
Strong
Tropism
Anisotropic
Reflectance R%
(45,39) 470, (40,34) 640
Reflected-light panel
42.5 %anisotropic · dual curve
Specimen sRGB 226, 162, 93
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Strong
Reflected colour
White

Crystallography

Crystal system
Monoclinic
Space group
C2/m
Cell parameters
a = 45.15 Å · b = 4.14 Å · c = 26.53 Å
Cell angles
β = 113.42 °
Ratio a:b:c
1 : 0.092 : 0.588
Z
2
Morphology

Equant to thin tabular

Twinning

Irregular lamellae in polished sections

Type-locality form

Loose crystal fragments, equant to thin tabular.

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
82PbLeadLead9207.2001864.800
37.86%
51SbAntimonyAntimony11121.7601339.360
27.19%
16SSulfurSulfur2632.060833.560
16.93%
33AsArsenicArsenic1174.922824.142
16.73%
29CuCopperCopper163.54663.546
1.29%
Total4925.408100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • IMA1966-031
  • IMA1966-032
  • Sorbyiet

In other languages

German
IMA 1966-032 · Sorbyit
Italian
Sorbyite

Classification

Strunz
10th ed.

2.LB.30

  • 2Sulfides and SulfosaltsClass
  • 2.LUnclassified SulfosaltsDivision
  • 2.LBWith essential PbGroup
  • 2.LB.30SorbyiteSpecies
Dana
8th ed.

03.06.12.01

  • 03SulfosaltsClass
  • 03.062 < ø < 2.49Type
  • 03.06.12— unnamed intermediate level —Group
  • 03.06.12.01SorbyiteSpecies
CIM

5.6.21

  • 5Sulphosalts - Sulpharsenites and Sulphobismuthites (those containing Sn, Ge,or V are in Section 6)Class
  • 5.6Sulpharsenites etc. of Pb aloneGroup
  • 5.6.21SorbyiteSpecies

Literature, links & citation

Citations
  1. 1967Jambor, John Leslie (1967) New lead sulfantimonides from Madoc, Ontario. Part 1. The Canadian Mineralogist, 9 (1) 7-24
  2. 1967Jambor, John Leslie (1967) New lead sulfantimonides from Madoc, Ontario. Part 2 - mineral descriptions. The Canadian Mineralogist, 9 (2) 191-213
  3. 1968Jambor, John Leslie (1968) New lead sulfantimonides from Madoc, Ontario. Part 3--Syntheses, paragenesis, origin. The Canadian Mineralogist, 9 (4). 505-521
  4. 1982Jambor, John L.; Laflamme, J. H. G.; Walker, D. A. (1982) A Re-examination of the Madoc Sulfosalts, in Ontario. The Mineralogical Record, 13 (2). 93-100
  5. 2005(2005) Sorbyite. Handbook of Mineralogy. Mineralogical Society of America
