Sphaerobertrandite

Be3(SiO4)(OH)2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Sbtd
Discovered
1957
Also known as
  • Sphaerobertrandiet
  • Sphaerobertrandita

Where it forms, where it's found

Geological setting

Alkaline pegmatites

Type locality
Tuften
  1. Tvedalen
  2. Larvik Commune
  3. Vestfold
  4. Norway

59.0346°, 9.8574°

10recorded occurrences
Source · OpenStreetMap

Safety & handling

Physical

Hardness
123456789105/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · white · yellow · brownish · greyish · beige.
Streak
White
Tenacity
brittle
Cleavage
Perfect

(001)

Fracture
Irregular/Uneven
Density
2.46 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 50 – 90°
Refractive index
1.597 – 1.616
Surface relief
Moderate
Principal indices
nα 1.597 · nβ 1.607 · nγ 1.616
Pleochroism
Weak

from yellowish (X) to colourless (Z), usually nonpleochroic

UV response
none
Michel-Lévy diagramhighlighted lineδ = 0.0190
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]190 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation190 nm
Order1st order
XPL colour

Crystallography

Crystal system
Monoclinic
Space group
P21/c
Cell parameters
a = 5.081 Å · b = 4.639 Å · c = 17.664 Å
Cell angles
β = 106.09 °
Ratio a:b:c
1 : 0.913 : 3.476
Unit cell volume
400 ų
Z
4
Morphology

Main crystal form is (001), small faces (012), (102) and {10-2} are present.

Twinning

Invariably twinned by pseudo-merohedry probably due to strongly pseudo-orthorhombic cell.

Type-locality form

Compact spherulites and aggregates, finely crystalline crusts and spherulites.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen615.99995.994
62.69%
14SiSiliconSilicon128.08528.085
18.34%
4BeBerylliumBeryllium39.01227.036
17.65%
1HHydrogenHydrogen21.0082.016
1.32%
Total153.131100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Sphaerobertrandiet
  • Sphaerobertrandita

In other languages

German
Sphaerobertrandit
Italian
Sferobertrandite · Sphaerobertrandite

Classification

Strunz
10th ed.

9.AE.50

  • 9SilicatesClass
  • 9.ANesosilicatesDivision
  • 9.AENesosilicates with additional anions (O,OH,F,H2O); cations in tetrahedral [4] coordinationGroup
  • 9.AE.50SphaerobertranditeSpecies

Literature, links & citation

Citations
  1. 1957Semenov, E.I. (1957) New hydrous silicates of beryllium-gelbertrandite and sphaerobertrandite. Trudy Institut Mineralogii, Geokhimii, Kristallokhim. Redkikh Elementov, Akademiia Nauk SSSR: 1: 64-69.
  2. 1958Fleischer, M. (1958) New Mineral Names. American Mineralogist, 43 (11-12). 1219-1225
  3. 2003Jambor, John L., Roberts, Andrew C. (2003) New mineral names. American Mineralogist, 88. 1836-1840
  4. 2003Pekov, Igor V., Chukanov, Nikita V., Larsen, Alf Olav, Merlino, Stefano, Pasero, Marco, Pushcharovsky, Dmitriy Y.u., Ivaldi, Gabriella, Zadov, Alexander E., Grishin, Viktor G., Åsheim, Arne, Taftø, Johan, Chistyakova, Nina I. (2003) Sphaerobertrandite, Be3SiO4(OH)2: new data, crystal structure and genesis. European Journal of Mineralogy, 15 (1) 157-166 doi:10.1127/0935-1221/2003/0015-0157 DOI: 10.1127/0935-1221/2003/0015-0157
  5. 2004Mandarino, Joseph A. (2004) New minerals. The Canadian Mineralogist, 42 (3) 921-945 doi:10.2113/gscanmin.42.3.921 DOI: 10.2113/gscanmin.42.3.921
