Steenstrupine-(Ce)

Na14Ce6Mn2+2Fe3+2Zr(PO4)7Si12O36(OH)2 · 3H2O
IMA status
  • Approved
  • Grandfathered
IMA symbol
Ssp-Ce
Also known as
  • Steenstrupine

Where it forms, where it's found

Type locality
Kangerluarsuk Fjord
  1. Ilímaussaq complex
  2. Kujalleq
  3. Greenland

60.8759°, -45.8737°

29recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
black · dark brown · red-brown
Streak
white, brownish white
Cleavage
None Observed
Fracture
Conchoidal
Density
3.38 g/cm³

Optical

Optical type
Uniaxial (-)
Refractive index
1.662 – 1.667
Surface relief
High
Principal indices
nω 1.665 – 1.667 · nε 1.662 – 1.663
Pleochroism
Weak

brown and yellow tints.

Michel-Lévy diagramhighlighted lineδ = 0.0035
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]35 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation35 nm
Order1st order
XPL colour

Crystallography

Crystal system
Trigonal
Space group
R-3m
Cell parameters
a = 10.460(4) Å · c = 45.479(15) Å
Z
3
Morphology

Rhombohedral crystals, rounded and rough, to 10 cm; massive.

Comment

commonly metamict.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
8OOxygenOxygen6915.9991103.931
35.14%
58CeCeriumCerium6140.116840.696
26.76%
14SiSiliconSilicon1228.085337.020
10.73%
11NaSodiumSodium1422.990321.860
10.25%
15PPhosphorusPhosphorus730.974216.818
6.90%
26FeIronIron255.845111.690
3.56%
25MnManganeseManganese254.938109.876
3.50%
40ZrZirconiumZirconium191.22491.224
2.90%
1HHydrogenHydrogen81.0088.064
0.26%
Total3141.179100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Th

Synonyms

  • Steenstrupine

In other languages

German
Steenstrupin-(Ce)
Italian
Steenstrupina- · steenstrupina-(Ce)

Classification

Strunz
10th ed.

9.CK.20

  • 9SilicatesClass
  • 9.CCyclosilicatesDivision
  • 9.CK[Si6O18]12- 6-membered single rings, with insular complex anionsGroup
  • 9.CK.20Steenstrupine-(Ce)Species
Dana
8th ed.

61.04.02.01

  • 61Cyclosilicates Six-membered RingsClass
  • 61.04Six-Membered Rings with other anionsType
  • 61.04.02Steenstrupine groupGroup
  • 61.04.02.01Steenstrupine-(Ce)Species
CIM

17.6.13

  • 17Silicates Containing other AnionsClass
  • 17.6Silicates with phosphateGroup
  • 17.6.13Steenstrupine-(Ce)Species

Group, growth & confusion

In the same group
1 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. 1882Lorenzen, Joh. (1882) On some Minerals from the Sodalite-Syenite in Juliane-haab district, south Greenland. Mineralogical Magazine and Journal of the Mineralogical Society, 5 (23) 49-70 doi:10.1180/minmag.1882.005.023.02 DOI: 10.1180/minmag.1882.005.023.02
  2. 1962Kupriyanova, I.I., Stolyarova, T.I., Sidorenko, G.A. (1962) A new thorium silicate - thorosteenstrupine. Zapiski Vserossijskogo Mineralogicheskogo Obshchestva: 91: 325-330.
  3. 1963Fleischer, Michael (1963) New Mineral Names. American Mineralogist, 48 (3-4) 433-436
  4. 1967IMA (1967) International Mineralogical Association: Commission on New Minerals and Mineral Names. Mineralogical Magazine and Journal of the Mineralogical Society, 36 (277) 131-136 doi:10.1180/minmag.1967.036.277.20 DOI: 10.1180/minmag.1967.036.277.20
  5. 1983Moore, P.B., Shen, J. (1983) Crystal structure of steenstrupine: a rod structure of unusual complexity. Tschermaks Mineralogische und Petrographische Mitteilungen: 31: 47-67.
