Stenonite

Sr2Al(CO3)F5
IMA status
  • Approved
IMA symbol
Sten
Discovered
1962
Also known as
  • Stenoniet

Where it forms, where it's found

Geological setting

Contact between cryolite-siderite and fluorite rich rocks.

Type locality
Ivigtut Mine
  1. Ivigtut stock
  2. Arsuk Fjord
  3. Sermersooq
  4. Greenland

61.2061°, -48.1756°

2recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789103.5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Transparent · Translucent
Colour
Colourless · white
Cleavage
Distinct/Good

Good on (001) (120)

Density
3.86 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 43° · 2V calc = 40°
Refractive index
1.452 – 1.538
Surface relief
Low
Principal indices
nα 1.452 · nβ 1.527 · nγ 1.538
Dispersion
r > v distinct
Michel-Lévy diagramhighlighted lineδ = 0.0860
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]860 nm2nd order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation860 nm
Order2nd order
XPL colour

Crystallography

Crystal system
Monoclinic
Cell parameters
a = 5.450(2) Å · b = 8.704(2) Å · c = 13.050(3) Å
Cell angles
β = 98.72(2) °
Ratio a:b:c
1 : 1.597 : 2.394
Z
4
Morphology

Massive

Type-locality form

Cleavable, massive, to 4 cm.

Comment

Space Group: P21/n.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
38SrStrontiumStrontium287.620175.240
49.06%
9FFluorineFluorine518.99894.990
26.59%
8OOxygenOxygen315.99947.997
13.44%
13AlAluminiumAluminium126.98226.982
7.55%
6CCarbonCarbon112.01112.011
3.36%
Total357.220100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Synonyms

  • Stenoniet

In other languages

German
Stenonit
Italian
Stenonite

Classification

Strunz
10th ed.

3.CG.05

  • 3HalidesClass
  • 3.CComplex halidesDivision
  • 3.CGAluminofluorides with CO3, SO4, PO4Group
  • 3.CG.05StenoniteSpecies
Dana
8th ed.

12.01.01.01

  • 12Compound HalidesClass
  • 12.01MiscellaneousType
  • 12.01.01— unnamed intermediate level —Group
  • 12.01.01.01StenoniteSpecies
CIM

12.1.7

  • 12Carbonates with other anionsClass
  • 12.1Carbonates with halidesGroup
  • 12.1.7StenoniteSpecies

Literature, links & citation

Citations
  1. 1962Pauly H (1962) Stenonite. A new carbonate-fluoride from Ivigtut, South Greenland. Meddelelser om Grønland 169(9): 1-24. https://rruff.info/rruff_1.0/uploads/MOG169_1.pdf
  2. 1963Fleischer, M. (1963) New mineral Names. American Mineralogist, 48 (9-10) 1178-1184
  3. 1967IMA (1967) International Mineralogical Association: Commission on New Minerals and Mineral Names. Mineralogical Magazine and Journal of the Mineralogical Society, 36 (277) 131-136 doi:10.1180/minmag.1967.036.277.20 DOI: 10.1180/minmag.1967.036.277.20
  4. 1984Hawthorne, F. C. (1984). The crystal structure of stenonite and the classification of the aluminofluoride minerals. The Canadian Mineralogist, 22(2), 245-251.
  5. 2005(2005) Stenonite. Handbook of Mineralogy. Mineralogical Society of America
