Štěpite

U(AsO3OH)2 · 4H2O
IMA status
  • Approved
IMA symbol
Ště
IMA approved
2012
Also known as
  • IMA2012-006
  • Štěpiet
  • UM1997-20-AsO:HU

Where it forms, where it's found

Geological setting

at the surface of native arsenic lens, at the joint of Geschieber and Geier veins within Ag-As-Bi-Co-Ni-U hydrothermal vein-type deposit

Type locality
Geschieber vein
  1. Svornost Mine
  2. Jáchymov
  3. Karlovy Vary District
  4. Karlovy Vary Region
  5. Czech Republic

50.3725°, 12.9117°

2recorded occurrences
Source · OpenStreetMap

Radioactivity

Physical

Hardness
123456789102/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Colour
Emerald green
Streak
Gray to greenish gray
Tenacity
brittle
Cleavage
Very Good

(001)

Fracture
Irregular/Uneven
Density
3.90 g/cm³

Optical

Optical type
Biaxial (-) · 2V measured = 5° · 2V calc = 43°
Refractive index
1.636 – 1.672
Surface relief
High
Principal indices
nα 1.636 · nβ 1.667 · nγ 1.672
Pleochroism
Non-pleochroic
Dispersion
2V(meas.) or β possibly incorrect
UV response
none
Notes

anomalous interference - grayish to pale yellow - on the (001) plane

Michel-Lévy diagramhighlighted lineδ = 0.0360
Attainable Michel-Lévy rangeΔ ∈ [0, t·δmax]360 nm1st order
Δ = 0Δmax
Thin-section mosaic70 grains · random 3D orientations
PPLpleochroism per grain
XPLindependent extinctions · rotate the stage
Interference simulatorsingle grain · PPL ↔ XPL
PPLpleochroism only · colour blends on rotation
XPLinterference colour · extinct every 90°
Retardation360 nm
Order1st order
XPL colour

Crystallography

Crystal system
Tetragonal
Space group
I41/acd
Cell parameters
a = 10.9894(1) Å · c = 32.9109(6) Å
Unit cell volume
3959.7 ų
Type-locality form

crystalline crusts of tabular crystals (the crystals are up to 0.6 mm, showing (001) and (100)), that exist in aggregates up to 6 mm; also blocky intergrowths of crystals; minute radiating aggregates of thin plates

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
92UUraniumUranium1238.029238.029
40.35%
8OOxygenOxygen1215.999191.988
32.54%
33AsArsenicArsenic274.922149.844
25.40%
1HHydrogenHydrogen101.00810.080
1.71%
Total589.941100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • S

Synonyms

  • IMA2012-006
  • Štěpiet
  • UM1997-20-AsO:HU

In other languages

German
IMA 2012-006 · Štěpit
Italian
štěpite

Classification

Strunz
10th ed.

8.CJ.45

  • 8Phosphates, Arsenates, VanadatesClass
  • 8.CPhosphates without additional anions, with H2ODivision
  • 8.CJWith only large cationsGroup
  • 8.CJ.45ŠtěpiteSpecies

Literature, links & citation

Citations
  1. 2012Williams, P. A., Hatert, F., Pasero, M., Mills, S. J. (2012) New minerals and nomenclature modifications approved in 2012. CNMNC Newsletter No 13. Mineralogical Magazine, 76 (3) 807-817 doi:10.1180/minmag.2012.076.3.26 DOI: 10.1180/minmag.2012.076.3.26
  2. 2013Plášil, J., Fejfarová, K., Hloušek, J., Škoda, R., Novák, M., Sejkora, J., Čejka, J., Dušek, M., Veselovský, F., Ondruš, P., Majzlan, J., Mrázek, Z. (2013) Štěpite, U(AsO3OH)2·4H2O, from Jáchymov, Czech Republic: the first natural arsenate of tetravalent uranium. Mineralogical Magazine, 77 (1) 137-152 doi:10.1180/minmag.2013.077.1.12 DOI: 10.1180/minmag.2013.077.1.12
  3. 2023(2023) Štěpite. Handbook of Mineralogy. Mineralogical Society of America
