Stibiopalladinite

Pd5Sb2
IMA status
  • Approved
  • Grandfathered
IMA symbol
Stpdn
Discovered
1927
Also known as
  • Allopalladium
  • Eugenesit
  • Eugenesita
  • +3 more

Where it forms, where it's found

Type locality
Tweefontein Farm
  1. Mokopane
  2. Mogalakwena Local Municipality
  3. Waterberg District Municipality
  4. Limpopo
  5. South Africa

-24.0028°, 28.8333°

92recorded occurrences
Source · OpenStreetMap

Physical

Hardness
123456789104 – 5/ 10 MOHS
  1. 1Talc
  2. 2Gypsum
  3. 3Calcite
  4. 4Fluorite
  5. 5Apatite
  6. 6Orthoclase
  7. 7Quartz
  8. 8Topaz
  9. 9Corundum
  10. 10Diamond
Transparency
Opaque
Colour
Silver · white to steel-gray · also pale brownish-yellow
Streak
Black
Density
10.8 g/cm³

Optical

Pleochroism
Weak

In pale yellow to yellowish white, also sometimes faint greenish, pinkish, or lavender.

Optical colour
Yellowish white
Anisotropism
Distinct, colors usually lacking but some grains are purplish gray to greenish gray.
Tropism
Anisotropic
Reflectance R%
(39.9,40.6) 400, (42.2,43.4) 420, (44.5,46.2) 440, (46.6,48.5) 460, (48.4,50.4) 480, (50.0,52.0) 500, (51.4,53.2) 520, (52.5,54.2) 540, (53.5,54.8) 560, (54.4,55.2) 580, (55.4,55.6) 600, (56.4,56.0) 620, (57.4,56.6) 640, (58.6,57.1) 660, (59.7,57.6) 680, (61.0,58.3) 700
UV response
Not fluorescent in UV
Reflected-light panel
52.0 %anisotropic · dual curve
Specimen sRGB 255, 178, 89
White reference100 % reflector under same lamp
R₁ R₂
Mode
Anisotropism
Distinct, colors usually lacking but some grains are purplish gray to greenish gray.
Reflected colour
Yellowish white

Crystallography

Crystal system
Hexagonal
Cell parameters
a = 7.598(2) Å · c = 28.112(9) Å
Z
12
Twinning

Ubiquitous

Type-locality form

Particles large enough to be seen with the naked eye.

Comment

Point Group: 6/m 2/m 2/m, 6mm, or _6m2. Space Group: P63/mmc, P63mc, or P_62c.

Crystal structure

Chemical composition

Constituent elements
Mass composition breakdown
ElementAtoms At. mass g/mol Mass g/molMass share
46PdPalladiumPalladium5106.420532.100
68.60%
51SbAntimonyAntimony2121.760243.520
31.40%
Total775.620100.00%

Mass share = atoms × atomic mass ÷ molar mass × 100

From IMA formula

Impurities
  • Cu
  • Sn
  • As

Synonyms

  • Allopalladium
  • Eugenesit
  • Eugenesita
  • Eugenesite
  • Stibiopalladiniet
  • Stibiopalladinita

In other languages

French
Stibiopalladinite
German
Stibiopalladinit
Spanish
Estibiopaladinita
Italian
Stibiopalladinite
Japanese
安パラジウム鉱
Russian
стибиопалладинит
Arabic
ستيبيوبالادينيت

Classification

Strunz
10th ed.

2.AC.20a

  • 2Sulfides and SulfosaltsClass
  • 2.AAlloysDivision
  • 2.ACAlloys of metalloids with PGEGroup
  • 2.AC.20aStibiopalladiniteSpecies
Dana
8th ed.

02.03.03.01

  • 02SulfidesClass
  • 02.03AmBnXp, with (m+n):p = 5:2Type
  • 02.03.03— unnamed intermediate level —Group
  • 02.03.03.01StibiopalladiniteSpecies
CIM

3.12.32

  • 3Sulphides, Selenides, Tellurides, Arsenides and Bismuthides (except the arsenides, antimonides and bismuthides of Cu, Ag and Au, which are included in Section 1)Class
  • 3.12Sulphides etc. of the platinum metalsGroup
  • 3.12.32StibiopalladiniteSpecies

Group, growth & confusion

In the same group
1 members
Often grow together
1 mineral

Literature, links & citation

Citations
  1. Bayliss, P. (1990) Revised unit cell dimensions, space group, and chemical formula of some metallic minerals. Canadian Mineralogist: 28: 751-755.
  2. Genkin, A.D., Tischendorf, G., Laputina, I.P. (1977) Über „Allopalladium“ von Tilkerode im Harz, DDR. Zeitschrift für Geologische Wissenschaften: 5: 1003–1009. [as allopalladium]
  3. 1924Spencer, L. J. (1924) Allopalladium from British Guiana. Mineralogical Magazine and Journal of the Mineralogical Society, 20 (105). 217-219 doi:10.1180/minmag.1924.020.105.04DOI: 10.1180/minmag.1924.020.105.04
  4. 1927Adam, H.R. (1927) A note on a new palladium mineral from the Potgietersrust platinum fields. The Journal of the Chemical, Metallurgical & Mining Society of South Africa: 27: 249-250.
  5. 1930Foshag W F (1930) New mineral names. American Mineralogist 15, 242-242
